Molex PicoBlade Series Right Angle Through Hole PCB Header, 12 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 53048-1210
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | PicoBlade |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.3mm |
Key Features
- Supports 1 A current capability in a compact 1.25 mm pitch design.
- Right angle through hole mount type ensures sturdy PCB attachment.
- Shrouded housing provides protection and prevents accidental unmating.
- Made with nylon housing and phosphor bronze contacts plated with tin.
- Operates reliably between -40°C and 85°C temperature range.
- Features a friction locking mechanism for secure mating connections.
- Suitable for high-density wire-to-board interconnection applications.
- Compact design saves up to 45% PCB space compared to 2.00 mm pitch systems.
Product Description
Molex 53048-1210 PicoBlade Series PCB Header is a high-density right angle through hole connector featuring 12 contacts arranged in a single row with 1.25 mm pitch. It supports a current rating of 1 A and a voltage rating of 125 V, making it suitable for various electronic assembly applications.
The connector housing is made from durable nylon material that is shrouded to protect contacts and prevent accidental disconnects, ensuring long-term reliability. The contacts are constructed from phosphor bronze and plated with tin to provide excellent conductivity and corrosion resistance.
Designed for through-hole PCB mounting, this connector includes a friction locking mechanism that protects against vibration and mishandling, securing the mated connection firmly. The tail pins extend 2.3 mm for reliable solder termination. Operating temperature ranges from -40°C to 85°C accommodate a wide variety of industrial environments.
This PicoBlade connector series offers up to 45% PCB space savings over conventional 2.00 mm pitch systems, ideal for compact, high-density electronic devices. Typical applications include automotive alarm systems, car audio, DVD players, industrial process controls, and medical patient monitors.
Supports 1 A current capacity in a compact pitch. Shrouded nylon housing enhances reliability and protection. Right angle through-hole mount for sturdy PCB integration. Phosphor bronze contacts with tin plating ensure conductivity and longevity.
Friction lock mechanism secures mating connection. Wide operating temperature range of -40°C to 85°C. Compact design saves PCB space by up to 45%. Tail pin length of 2.3 mm for robust soldering.
It fits within the Electronics & Electricals category specializing in PCB Headers for professional and industrial electronic assembly and manufacturing. Explore more Molex products and PCB Header variants on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 1 A and a voltage rating of 125 V.
The pitch size of this connector is 1.25 mm.
The housing is made from nylon, and the contacts are constructed from phosphor bronze with tin plating.
It operates reliably within a temperature range of -40°C to 85°C.
This model features 12 contacts arranged in a single row.
This connector uses a right angle through hole mount type for sturdy PCB attachment.
The tail pin length is 2.3 mm, designed for reliable solder termination.
Yes, it includes a friction locking mechanism to secure the mating connection and protect against vibration.
Typical applications include automotive alarm systems, car audio, DVD players, industrial process controls, and medical patient monitors.
The housing of this connector is shrouded, providing protection and preventing accidental unmating.
It belongs to the wire-to-board connector system, suitable for high-density interconnections.
The country of origin for this product is India.
