Wurth Elektronik WR-FPC 0.5 mm Pitch 10 Way Horizontal Female FPC Connector ZIF Bottom Contact 687110149022

Wurth Elektronik 687110149022 is a 0.5 mm pitch 10 way horizontal female FPC connector featuring a zero insertion force (ZIF) bottom contact design. This Surface Mount Technology (SMT) connector includes a hinged flip-lock actuator that secures the flexible printed circuit (FPC) or flat flex cable (FFC) firmly to the connector terminals, ensuring high reliability and secure mating.

The connector is engineered with phosphor bronze contacts plated with tin over nickel, delivering excellent conductivity and corrosion resistance. Its polyamide housing provides a lightweight and compact footprint, suited for high density applications where space saving is crucial.

Capable of carrying up to 500mA current at 50V ac, the connector is designed to operate in harsh environments with a temperature range from -40°C minimum to 105°C maximum, making it suitable for industrial, instrumentation, and consumer electronics applications.

This 10 position single row FPC Connector's horizontal orientation and ZIF insertion force mechanism allow easy installation and removal without damaging the delicate contacts. The locking mechanism further enhances connection security, making it ideal for applications requiring stable and repetitive connections.

Typical use cases include interfacing small display modules, keyboards, and other miniature electronic assemblies where reliable, low-profile cable-to-board connections are needed. Manufactured in China, this connector conforms to the WR-FPC series standards by Wurth Elektronik.

Features 10 contacts with 0.5 mm pitch for precise signal transmission. Constructed using phosphor bronze contacts plated with tin over nickel for durability. Surface mount type connector designed with a hinged flip-lock actuator for secure cable retention.

Supports a maximum current of 500mA and voltage of 50V AC. Operates reliably in a temperature range from -40°C to 105°C. Horizontal orientation with bottom contact and ZIF insertion force for easy assembly. Housing made from polyamide material ensuring lightweight and space-saving design.

Locking mechanism included for enhanced connection stability. Single row connector suitable for applications interfacing with small displays and keyboards. Browse the Electronics Components category on EnvMart for more high quality connectors and FPC solutions by reputable brands including Wurth Elektronik.
