Nexperia N-Channel MOSFET 850 mA, 30 V Enhancement Mode, 3-Pin SOT-23 Package BSH103,215

Nexperia BSH103,215 is a high-reliability N-Channel MOSFET transistor designed for electronic circuit switching and amplification, capable of handling up to 850 mA continuous drain current and a maximum drain-source voltage of 30 V. This device features enhancement mode channel operation with a low on-resistance of 400 milliohms ensuring efficient conduction and energy savings.

Housed in a compact and widely used 3-pin SOT-23 surface mount package, it enables small-form-factor designs, making it ideal for embedded and miniaturized electronics in industrial, laboratory, consumer electronics, and automotive applications.

The MOSFET operates reliably in wide temperature ranges from -55°C to 150°C, supporting demanding environmental conditions. Its typical gate charge of 2.1 nC and maximum gate-source voltage limits of ±8 V allow fast switching and compatibility with standard gate drive circuits.

This transistor provides a power dissipation capacity of up to 500 mW which supports various low power switching tasks in power management, signal processing, and control circuits. Dimensions of 3 mm length x 1.4 mm width x 1 mm height facilitate easy PCB layout and integration.

Supports a continuous drain current of 850 mA. Operates at a maximum drain-source voltage of 30 V. Uses enhancement mode with N-channel type for efficient switching. Compact SOT-23 3-pin package suitable for surface mounting.

Maximum drain-source resistance (Rds) of 400 milliohms ensuring low conduction losses. Capable of dissipating up to 500 milliwatts power during operation. Operational temperature range from -55°C to 150°C for reliability.

Typical gate charge of 2.1 nanocoulombs at Vgs, optimizing switching speed. Maximum gate-source voltage is ±8 V, compatible with standard gate drive voltages. Dimensions 3 mm length, 1.4 mm width, 1 mm height for compact PCB integration.

Common usage includes switching applications, power management in electronic devices, signal amplification, and integration in industrial and automotive electronic control systems.
