DiodesZetex High Side 2 Channel Power Switch IC, Surface Mount SOIC 8-Pin, 2.7 to 5.5 V, 2.6 A AP2191SG-13

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex High Side 2 Channel Power Switch IC, Surface Mount SOIC 8-Pin, 2.7 to 5.5 V, 2.6 A AP2191SG-13

Name: DiodesZetex High Side 2 Channel Power Switch IC, Surface Mount SOIC 8-Pin, 2.7 to 5.5 V, 2.6 A AP2191SG-13
Brand: DiodesZetex
SKU: 136769
Price: 1.1 USD
Availability: InStock



Category Power Switch ICs Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.5mm
Length	4.95mm
Model	AP2191SG-13
Width	3.95mm
Mount Type	Surface
Number of inputs	2
Series	AP2191
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Operating Current	2.6A
Number of outputs	2
Pin Count	8
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	2.7V
Switch On Resistance RdsOn	115mΩ

Key Features

This power switch IC features low switch on resistance of 115 milliohms for efficient power control.
Designed with two outputs and two inputs for versatile switching applications.
Compact SOIC 8-Pin surface mount package allows easy PCB integration.
Operates over a temperature range of -40°C to 85°C.
Maximum supply voltage of 5.5 V ensures compatibility with common low voltage systems.
The device is suitable for use in power management of electronic devices and industrial systems.
Manufactured with robust construction to ensure reliable switching performance under industrial conditions.

Product Description

DiodesZetex AP2191SG-13 is a compact, high side power switch IC designed for efficient power control in electronic and industrial applications. This device is housed in an 8-pin SOIC surface mount package, making it suitable for automated assembly and space-constrained PCB layouts. It operates with a supply voltage range from 2.7 V minimum to 5.5 V maximum and supports an operating current of up to 2.6 A.

The AP2191SG-13 incorporates two outputs and inputs with a low switch on resistance of 115 milliohms, minimizing power loss and heat generation during operation. It is capable of functioning in harsh thermal environments with operating temperatures ranging from -40°C to 85°C, making it suitable for automotive, industrial control, and power management systems.

This power switch IC’s surface mount design assures easy integration into modern electronic assemblies requiring reliable high side switching. The device is typically employed in controlling loads, power distribution, and protection circuits in various semiconductor-based power management systems.

Key features include dual high side outputs, low on resistance, broad supply voltage compatibility, and robust temperature tolerance. This product is ideal for use in industrial electronics, automotive electronics, communication equipment, and other applications requiring efficient power switching.

This IC enables safe and efficient switching of power in low-voltage electronic circuits. Its surface mount SOIC package supports automated manufacturing processes. Designed to enhance device longevity with reliable operation at elevated temperatures.

Compatible with standard PCB layouts for easy design adoption and replacement. Suitable for use in power supply circuits, motor drives, and other embedded control modules.

DiodesZetex Power Switch ICs like the AP2191SG-13 exemplify the quality and innovation essential for modern power management needs. For exploring more power management components, browse the Electronics & Electricals category at EnvMart.
