| Country of Origin | China |
|---|---|
| Brand | HY Electronic Corp |
| Height | 2.24mm |
| Length | 4.7mm |
| Model | SS26 |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | FBI |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -65°C |
| Polarity | indicated by cathode band |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 400μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 0.7V |
| Moulded Plastic Case (Plastic | flammability classification UL 94V-0) |
HY Electronic Corp SS26 is a Schottky barrier rectifier diode designed for surface mount applications with a DO-214AA package. This diode offers a maximum continuous forward current of 2 A and peak reverse repetitive voltage of 60 V, making it suitable for power rectification and protection circuits in industrial, electronic, and automotive sectors.
The device features a low forward voltage drop (0.7 V max), which increases efficiency by reducing power losses in switching power supplies, free-wheeling diode applications, and inverters. Its peak forward surge current rating of 50 A allows it to withstand transient current spikes without damage.
Constructed with epitaxial technology and a metal-semiconductor junction with guarding, the SS26 diode ensures excellent electrical performance and reliability. The molded plastic case complies with UL 94V-0 flammability rating, enhancing safety in operation.
Operating temperature range from -65°C up to 125°C allows the diode to be deployed in harsh environments. The polarity is clearly marked with a cathode band, facilitating correct placement on PCB assemblies.
This diode is used extensively in semiconductor discrete component applications including power supplies, inverters, polarity protection circuits, and free-wheeling diode functions within various electronic and electrical systems.
Compact surface mount DO-214AA package for efficient PCB layout. Continuous forward current of 2 A suitable for medium power applications. Peak reverse repetitive voltage of 60 V supporting voltage tolerance in circuits.
Low forward voltage drop reduces conduction losses improving efficiency. Wide operating temperature range safe for industrial use. Plastic molded case rated UL 94V-0 for flame retardancy and mechanical protection. Manufactured to high standards in China ensuring quality and performance.
