HARWIN 2.54 mm Pitch Vertical 32 Way Through Hole Standard Pin Open Frame DIL Socket 1A D2832-42

HARWIN D2832-42 is a 32-way vertical DIL socket with a 2.54 mm pitch, designed for through hole mounting on printed circuit boards. This open frame DIL socket features standard pins and is rated for 1 Amp current and operating voltages up to 150V AC. It supports a wide range of operating temperatures from -55°C to 125°C, making it suitable for demanding industrial and electronic applications.

The contact material is a beryllium copper alloy plated with gold, providing excellent electrical conductivity and corrosion resistance. The housing is constructed from durable plastic, ensuring proper insulation and mechanical durability. The socket is compatible with pin diameters ranging between 0.41 mm and 0.56 mm, offering flexibility for various integrated circuit leads.

This DIL socket’s through hole mount type and vertical orientation provide robust mechanical retention on PCBs. Its dimensions are 40.6 mm in length, 17.64 mm in width, and 4.2 mm in depth, suitable for standard PCB layouts with a row width spacing of 15.24 mm. The solder termination ensures a reliable and lasting electrical connection.

Typical applications include electronic manufacturing, repair, and prototyping where reliable IC socket connections are critical. The open frame design facilitates easy component insertion, inspection, and rework when necessary.

This DIL socket features 32 contacts with a 2.54 mm pitch for standard IC integration. Open frame design allows easy inspection and soldering of components. Constructed with beryllium copper alloy contacts plated in gold for excellent conductivity and corrosion resistance.

Supports current rating of 1A and voltage rating up to 150V AC for versatile applications. Mount type is through hole with vertical orientation facilitating secure PCB mounting. Operating temperature range from -55°C to 125°C ensures durability in harsh environments.

Contact accommodates pin diameters from 0.41 mm to 0.56 mm, compatible with various IC leads. Termination type is solder, ensuring optimal electrical connection on PCB. Compact dimensions of 40.6 mm length, 17.64 mm width, and 4.2 mm depth fit standard layouts.

Plastic housing provides electrical insulation and mechanical stability. Ideal for industrial, electronic manufacturing, repair, and prototyping use cases requiring dependable IC connections. Explore EnvMart’s broad inventory of electronic components, including DIL Sockets and other IC adapters for diverse industrial, laboratory, and manufacturing environments.
