Wurth Elektronik WE-LHMI 8030 Shielded Wirewound Surface Mount Inductor Iron Core 8.2μH Moulded ±20% 4.3A 125°C 74437356082
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 3mm |
| Length | 9.7mm |
| Depth | 8.5mm |
| Packaging | Tape & Reel |
| Series | WE-LHMI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Iron |
| Inductance | 8.2μH |
| Standards/Approvals | RoHS, IEC 61249-2-21, JEDEC JS709B, REACH |
| Package/Case | 8030 |
| Maximum DC Current | 4.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 59.3mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 11MHz |
| Inductor Construction | Moulded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact surface mount design suitable for high current power applications.
- Magnetically shielded construction minimizes electromagnetic interference.
- Iron core and moulded construction provide durability and stability.
- Operating temperature range from -40°C to 125°C ensures reliability in harsh environments.
- Compliant with automotive standard AEC-Q200 and RoHS directive.
- Maximum DC resistance of 59.3mΩ allows efficient current flow.
- Inductance tolerance of ±20% for stable performance.
- High self-resonant frequency of 11MHz supports switching power supplies.
Product Description
Wurth Elektronik 74437356082 WE-LHMI Series shielded wirewound SMD power inductor featuring an iron core with 8.2μH inductance and 4.3 A maximum DC current rating. This moulded, magnetically shielded inductor is designed for reliable high current operation with minimal acoustic noise and electromagnetic leakage.
The 8030 package dimensions are 9.7 mm in length, 3 mm in height, and 8.5 mm in depth, making it suitable for space-constrained surface mount applications. Its robust iron core construction and moulded design ensure durability during PCB assembly and operation.
It operates effectively within a temperature range of -40°C to 125°C, making it well suited for automotive and industrial electronic systems. The inductor meets the AEC-Q200 automotive standard as well as RoHS, IEC 61249-2-21, JEDEC JS709B, and REACH standards for compliance and environmental safety.
The WE-LHMI Series inductors are commonly applied in DC-DC converters for high current power supplies, field programmable gate arrays (FPGA), POL converters, portable power applications such as PDAs and digital cameras, and mainboards or graphic cards. Their high current transient spike capability and shielding make them ideal for noise-sensitive power circuits.
Compact surface mount design suitable for high current power applications. Magnetically shielded construction minimizes electromagnetic interference. Iron core and moulded construction provide durability and stability. Operating temperature range from -40°C to 125°C ensures reliability in harsh environments.
Compliant with automotive standard AEC-Q200 and RoHS directive. Maximum DC resistance of 59.3mΩ allows efficient current flow. Inductance tolerance of ±20% for stable performance. High self-resonant frequency of 11MHz supports switching power supplies.
Package size 8030 dimensions: length 9.7mm, height 3mm, depth 8.5mm.
Choose Wurth Elektronik WE-LHMI series for reliable, low-noise, high-current inductors suitable for industrial, automotive, telecommunications, and consumer electronics applications. Explore more Surface Mount Inductors by Wurth Elektronik at EnvMart for advanced power circuit solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 8.2μH, with an inductance tolerance of ±20%.
It has a maximum DC current rating of 4.3A, allowing it to handle high current applications effectively.
The dimensions of the 8030 package are 9.7 mm in length, 3 mm in height, and 8.5 mm in depth.
This inductor operates effectively within a temperature range of -40°C to 125°C.
It features a moulded construction with an iron core, designed for durability and stability in operation.
It complies with automotive standard AEC-Q200, as well as RoHS, IEC 61249-2-21, JEDEC JS709B, and REACH standards.
The maximum DC resistance is 59.3mΩ, which allows for efficient current flow.
The maximum self-resonant frequency is 11MHz, supporting its use in switching power supplies.
This model uses a surface mount termination style, suitable for compact applications.
It is packaged in tape and reel format, which is common for surface mount components.
It is commonly applied in DC-DC converters, field programmable gate arrays (FPGA), and portable power applications such as PDAs and digital cameras.
This inductor has a pin count of 2, making it suitable for various circuit designs.
