| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | 1N4448HWS-7-F |
| Width | 1.4mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Power Dissipation Pd | 200mW |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 1.25V |
| Peak Reverse Recovery Time trr | 4ns |
| Maximum Forward Current If | 500mA |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 80V |
The DiodesZetex 1N4448HWS-7-F is a high-performance silicon junction switching diode designed for surface mount applications requiring compact size and reliable operation. Rated for a maximum forward current of 500 mA and peak repetitive reverse voltage of 80 V, it is ideal for electronic circuits needing efficient switching capabilities.
This device features a low peak reverse recovery time of 4 ns, enabling high-speed switching in industrial, automotive, and consumer electronics. It supports a wide operating temperature range from -65°C to 150°C, ensuring stable function under demanding environmental conditions.
Encased in a SOD-323 package with 2 pins, the diode dimensions are 1.8 mm in length, 1.4 mm in width, and 1.1 mm in height. It dissipates a maximum power of 200 mW and withstands peak non-repetitive forward surge currents up to 4 A, providing durability for transient conditions.
Applications include switching circuits in power supplies, signal processing, and other discrete semiconductor uses requiring fast Switching Diodes. The silicon junction technology assures consistent performance and longevity.
The diode supports a maximum power dissipation of 200 mW. It features a peak reverse recovery time of 4 nanoseconds, suitable for fast switching applications. Operating temperature ranges from -65°C to 150°C for reliable performance in harsh environments.
Package dimensions are approximately 1.8 mm length, 1.4 mm width, and 1.1 mm height. Designed for surface mount assembly with a 2-pin configuration. Maximum forward voltage is 1.25 V under standard conditions. Capable of handling a peak non-repetitive forward surge current of 4 A.
Constructed with silicon junction semiconductor technology for efficient switching. Set contains 1 Pc DiodesZetex 1N4448HWS-7-F switching diode. Explore more semiconductor and diode products in the DiodesZetex range at EnvMart for industrial, electronic, and manufacturing systems.
