Vishay 38 kHz IR Receiver ±75° Angle, 40 m Transmission Range, 2.5 V to 5.5 V Supply, Surface Mount TSOP TSOP57238TT1
Specifications
| Country of Origin | Philippines |
|---|---|
| Brand | Vishay |
| Orientation | Top View |
| Height | 0.8mm |
| Length | 3.95mm |
| Model | TSOP57238TT1 |
| Packaging | Tape & Reel |
| Width | 3.95mm |
| Mount Type | Surface |
| Output Current | 5mA |
| Maximum transmission distance | 40m |
| Maximum Operating Temperature | 85°C |
| Package Type | TSOP |
| Minimum Operating Temperature | -25°C |
| Standards/Approvals | JEDEC |
| Number of Pins | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.5V |
| Supply Current | 5mA |
| Carrier Frequency | 38kHz |
| Angle of Half Transmission Distance | ±75° |
Key Features
- Operates at a 38 kHz carrier frequency with ±75° angle coverage.
- Maximum transmission distance of 40 meters for long-range IR reception.
- Compact surface mount TSOP package with 8 pins for easy PCB integration.
- Wide operating temperature range from -25°C to 85°C ensuring durability.
- Low supply voltage from 2.5 V to 5.5 V with a supply current of 5 mA.
- Compliant with JEDEC standards for quality assurance.
- Manufactured in the Philippines, suitable for various IR communication applications.
- Packaged in tape and reel format for manufacturing efficiency.
Product Description
Vishay TSOP57238TT1 is a high-sensitivity IR remote control receiver designed for use in infrared communication, code learning, repeaters, light barriers, and proximity sensors. Operating at a carrier frequency of 38 kHz, it supports a maximum transmission distance of 40 meters and offers a wide angular reception of ±75°. This receiver is housed in a compact surface mount TSOP package with dimensions of 3.95 mm width, 0.8 mm height, and 3.95 mm length.
The device supports a low supply voltage range from 2.5 V to 5.5 V and consumes a typical supply current of 5 mA, making it energy-efficient for various electronics applications. It is rated for operation in temperatures from -25°C to 85°C, ensuring reliable performance in diverse environments.
Compliance with JEDEC standards guarantees quality and interoperability. The 8-pin surface mount configuration facilitates easy integration into PCB layouts, suitable for industrial, consumer electronics, home automation, and manufacturing systems requiring infrared remote control and sensing.
Carrier frequency: 38 kHz for robust IR signal detection. Angle of half transmission distance ±75° enables wide coverage. Maximum transmission distance: 40 meters for long-range IR communication. Surface mount package (TSOP) with an 8-pin layout for compact assembly.
Operating temperature range from -25°C to 85°C for industrial and consumer reliability.
This Vishay IR receiver offers a reliable solution for applications requiring accurate infrared sensing and remote control capabilities, including automation and communication devices. It is supplied on tape and reel packaging optimized for automated manufacturing processes.
Explore more Vishay electronics components and IR Receivers at EnvMart for your industrial and electronic application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TSOP57238TT1 operates at a carrier frequency of 38 kHz, which is suitable for robust IR signal detection.
This model supports a maximum transmission distance of 40 meters, allowing for long-range infrared communication.
The device operates with a supply voltage range from 2.5 V to 5.5 V, making it versatile for various applications.
It has an operating temperature range from -25°C to 85°C, ensuring reliable performance in diverse environments.
This IR receiver features an 8-pin configuration, facilitating easy integration into PCB layouts.
The TSOP57238TT1 is packaged in tape and reel format, which is optimized for automated manufacturing processes.
It has an angle of half transmission distance of ±75°, providing wide coverage for infrared reception.
The typical supply current for this model is 5 mA, contributing to its energy efficiency.
It is compliant with JEDEC standards, ensuring quality and interoperability in electronic applications.
The height of this model is 0.8 mm, making it compact for surface mount applications.
This IR receiver is designed for infrared communication, code learning, repeaters, light barriers, and proximity sensors.
The device is manufactured in the Philippines, ensuring compliance with quality standards.
