onsemi 6-Channel Non-Inverting Current/Voltage Buffer, 16-Pin SOIC MC14050BDR2G

onsemi MC14050BDR2G is a 6-channel non-inverting current/voltage buffer designed to operate within a wide voltage range from 3V to 18V. It comes in a 16-pin SOIC surface mount package, offering a compact solution ideal for various electronic and semiconductor applications. The device uses CMOS logic input and provides non-inverting buffer output functionality, enabling accurate signal buffering and conditioning in complex circuits.

This buffer features a maximum propagation delay time of 140ns at specified load capacitance, allowing efficient signal handling at moderate speeds. Its low supply current of just 15μA makes it suitable for low-power electronic designs. The operating temperature range from -55°C to 125°C allows for reliable performance under extreme thermal conditions, suitable for automotive and industrial environments given its compliance with the AEC-Q100 standard.

The MC14050BDR2G provides six independent channels, making it efficient for multi-channel buffering applications in logic circuits. Its output current capabilities feature a maximum high-level output current of -4.7mA and a maximum low-level output current of 30mA, ensuring strong drive strengths for downstream components. The device is a part of the 4000 CMOS logic family and MC14 series, known for robust logic functionality and wide voltage range interfacing.

Applications span across industrial, automotive, manufacturing, and electronic circuit design requiring reliable voltage and current buffering. This product supports surface mount assembly processes enhancing production efficiency, and is packaged supplied on reels suitable for automated insertion machinery.

The buffer does not incorporate Schmitt trigger inputs but relies on CMOS input logic type for standard buffering tasks. Overall, the MC14050BDR2G is a versatile, durable semiconductor component designed for enhancing signal integrity in complex electronic systems.

Wide 3 to 18V operating voltage range for flexible integration. Non-inverting output buffer for accurate signal transmission. Low supply current ensures energy-efficient operation. High maximum temperature tolerance supports harsh environments.

16-pin SOIC surface mount package for compact designs. Six independent channels for multi-signal buffering. 140ns propagation delay time optimizes processing speeds. AEC-Q100 automotive standard compliant for reliability.

CMOS input type provides effective logic signal handling. Strong output current drive for downstream devices. Explore more semiconductor Logic ICs and buffers in EnvMart’s electronics category.
