| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.35mm |
| Length | 3.68mm |
| Model | MMSZ11T1G |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 11V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 20Ω |
| Surface Mount case | SOD-523 |
onsemi MMSZ11T1G Zener Diode is a high-quality single zener diode delivering a nominal voltage of 11 V with a 5% tolerance, designed for voltage regulation in electronic circuits. Its 500 mW maximum power dissipation enables effective protection and stable voltage management in various semiconductor applications.
Packaged in a compact SOD-123 surface mount case with a 3-pin configuration, this diode is suitable for automated PCB assembly, enhancing production efficiency. The diode supports a broad temperature range from -65°C to 150°C making it suitable for industrial, automotive, and commercial electronic devices that require durable voltage regulation components.
This component features a maximum reverse leakage current of 100 nA and a maximum Zener impedance of 20 ohms, ensuring low power dissipation and precise voltage control under typical operating currents. The test current for performance evaluation is set at 5 mA.
Compliant with RoHS standards, the MMSZ11T1G supports environmentally safe manufacturing requirements. This diode is essential in semiconductor discrete component applications, ideal for power supplies, voltage reference circuits, and signal conditioning roles in industrial and consumer electronics.
Single diode configuration ensuring precise voltage control. Nominal Zener voltage of 11 volts with 5% tolerance for accuracy. Maximum power dissipation rating of 500 milliwatts for stable operation. Surface mount package type SOD-123 with 3-pin design for PCB mounting.
Operating temperature range from -65°C to 150°C suitable for harsh environments. Maximum reverse leakage current is 100 nanoamps ensuring minimal power loss. Test current specified at 5 milliamps for reliable performance measurement.
RoHS compliant to meet environmental and safety standards.
Suitable for industrial, automotive, laboratory, and manufacturing use, the onsemi MMSZ11T1G is a reliable choice for critical electronic designs requiring stable voltage regulation. Explore more semiconductor components in our dedicated Electronics & Electricals category at EnvMart.
Explore more products in our Zener Diodes category.
