DiodesZetex Schmitt Trigger Input Inverter 6 Elements 14-Pin SOIC 4.5V to 5.5V 74HCT14S14-13
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.48mm |
| Length | 8.74mm |
| Model | 74HCT14S14-13 |
| Width | 3.99mm |
| Mount Type | Surface |
| Output type | Push Pull |
| Supply Voltage range | 4.5V to 5.5V |
| Series | 74HCT14 |
| Input Type | Schmitt Trigger |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Pin Count | 14 |
| Number of Elements per Chip | 6 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | HCT |
| Logic Function | Inverter |
| Minimum Supply Voltage | 4.5V |
| Maximum High Level Output Current | -4mA |
| Maximum Propagation Delay Time @ CL | 51ns |
| Maximum Low Level Output Current | 4mA |
| Sinks or Sources 4mA at VCC | 4.5V |
Key Features
- This inverter incorporates Schmitt trigger inputs for enhanced noise immunity and signal integrity.
- The device outputs are of push-pull type with a pin count of 14 for compact integration.
- Operates efficiently over a temperature range from -40°C to 125°C.
- Maximum propagation delay at load CL is 51 nanoseconds ensuring high-speed switching.
- Designed for surface mount with a standard SOIC package, measuring 8.74mm length, 3.99mm width, and 1.48mm height.
- Supplies current of ±4mA at 4.5V supply voltage suitable for low power consumption circuits.
- Logical family compliant with HCT series standards and compatible with low power Schottky TTL logic.
- Manufactured in China with no automotive or specific automotive approvals.
Product Description
DiodesZetex 74HCT14S14-13 is a high-speed CMOS logic inverter featuring Schmitt trigger inputs designed for use in industrial and electronic circuit applications requiring noise immunity and fast switching capabilities operating at supply voltages from 4.5V to 5.5V.
This device contains 6 inverter elements internally configured in a 14-Pin Small Outline Integrated Circuit (SOIC) package optimized for surface mounting on printed circuit boards.
With a maximum propagation delay time of 51 nanoseconds at standard load conditions, it provides reliable switching for medium-speed operations and ensures signal stability through Schmitt trigger inputs that effectively filter noisy input signals.
Operating temperatures are rated from -40°C to 125°C, making the product suitable for various industrial, telecommunications, and consumer electronics applications.
The 74HCT family logic IC is compatible with existing TTL logic standards and demonstrates low power consumption characteristics. It sources or sinks ±4mA output current at the nominal 4.5V power supply, ensuring versatility for interfacing with other logic devices in complex circuit designs.
Schmitt trigger input technology offers superior noise immunity and cleaner signal transitions. Push-pull output configuration suited for driving various load types with fast response. Standard SOIC 14-pin surface mount package dimensions facilitate high-density PCB layouts.
Wide supply voltage range allows flexible operation in diverse environments. Extended operating temperature range supports reliability in harsh industrial conditions. High ESD protection exceeding JEDEC standards assures device robustness.
The 74HCT14S14-13 inverter is ideal for industrial automation, embedded systems, control panels, instrumentation, laboratory equipment, and power electronics circuits. Its combination of speed, power efficiency, and noise immunity makes it a reliable component in modern electronic designs.
Explore the extensive range of semiconductor and Logic ICs at EnvMart to meet your design and manufacturing needs efficiently.
