STMicroelectronics 45 V 15 A Schottky Diode 3-Pin TO-252 Surface Mount STPS15L45CBY-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.4mm |
| Length | 6.6mm |
| Model | STPS15L45CBY-TR |
| Width | 6.2mm |
| Mount Type | Surface |
| Series | STPS15L45C-Y |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 15A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1A |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 0.4V |
Key Features
- Maximum continuous forward current of 15 amperes offers robust current handling.
- Peak reverse repetitive voltage rating of 45 volts ensures reliable blocking capability.
- Low forward voltage drop (0.4V) enhances energy efficiency and reduces heat.
- Compact TO-252 surface mount package with dimensions approximately 6.6mm x 6.2mm x 2.4mm.
- Wide operating temperature range from -40°C to 150°C supports harsh environments.
- Peak non-repetitive forward surge current up to 75 amperes for transient robustness.
- Common cathode diode configuration suitable for multiple circuit designs.
- Three-pin design allows easy PCB integration and mounting.
Product Description
STMicroelectronics STPS15L45CBY-TR is a high-performance Schottky barrier diode featuring a 45 V peak reverse voltage and 15 A maximum continuous forward current in a compact TO-252 3-pin surface mount package. This diode provides excellent efficiency and low forward voltage drop of 0.4 V, ideal for power rectification applications requiring fast switching and low loss.
Designed with a common cathode diode configuration, it is suitable for use in industrial power supplies, consumer electronics circuits, and other semiconductor applications where compact size and reliable thermal performance are critical. Its operating temperature range from -40°C to 150°C allows operation in demanding environmental conditions.
The device supports a peak non-repetitive forward surge current of 75 A, providing transient robustness during voltage spikes or switching events. The package dimensions of approximately 6.6 mm length, 6.2 mm width, and 2.4 mm height facilitate efficient PCB integration and mounting.
This Schottky diode does not carry automotive standard certification and is intended primarily for electronic component assemblies in industrial and commercial electronics manufacturing.
Maximum continuous forward current of 15 A ensures high load handling capability. Low forward voltage (0.4 V) reduces conduction losses. Peak reverse repetitive voltage of 45 V guarantees switching stability. Compact TO-252 surface mount package for space-saving PCB layout.
Wide temperature tolerance from -40°C to 150°C enables versatile use cases. Peak surges up to 75 A accommodate transient conditions. Reliable Schottky barrier technology with common cathode configuration. Three-pin layout for easy PCB assembly.
Designed for industrial, laboratory, and consumer electronics power rectification use. Explore the broader selection of Schottky diodes and rectifiers at EnvMart for various electronic design and manufacturing needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this Schottky diode is 15 amperes.
The peak reverse repetitive voltage rating for this model is 45 volts.
The forward voltage drop of this diode is 0.4 volts, which enhances energy efficiency.
The dimensions of the TO-252 package are approximately 6.6 mm in length, 6.2 mm in width, and 2.4 mm in height.
The operating temperature range for this diode is from -40°C to 150°C.
The peak non-repetitive forward surge current rating is up to 75 amperes.
This model uses a common cathode diode configuration.
This diode has a 3-pin design, facilitating easy PCB integration and mounting.
Yes, it is suitable for high-temperature applications due to its maximum operating temperature of 150°C.
This Schottky diode is designed for use in industrial power supplies, consumer electronics circuits, and other semiconductor applications.
The peak reverse current rating for this diode is 1 ampere.
The STPS15L45CBY-TR is manufactured in India.
