onsemi 9.1 V 550 mW Single Surface Mount Zener Diode 2-Pin DO-214AA 1SMB5924BT3G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.47mm |
| Length | 5.6mm |
| Model | 1SMB5924BT3G |
| Mount Type | Surface |
| Series | 1SMB59 |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 550mW |
| Diode Configuration | Single |
| Test Current It | 41.2mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 9.1V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 4Ω |
Key Features
- The diode configuration is single with a nominal Zener voltage of 9.1 V.
- Maximum power dissipation is rated at 550 mW, supporting efficient voltage regulation.
- The package type is DO-214AA suitable for surface mount technology.
- The device features a maximum reverse leakage current of 5 μA and a test current of 41.2 mA.
- It operates in temperature ranges from -65°C to 150°C ensuring reliability under various conditions.
- The package dimensions are compact with a length of 5.6 mm and height of 2.47 mm.
- Designed according to RoHS standards and meets AEC-Q101 automotive qualification.
- It has a maximum Zener impedance of 4 Ω ensuring stable voltage regulation.
Product Description
onsemi 1SMB5924BT3G is a single-element Zener diode optimized for voltage regulation with a nominal voltage of 9.1 V and a maximum power dissipation of 550 mW. This component is designed for surface mounting on circuit boards, enclosed in a compact DO-214AA 2-pin package ensuring ease of installation in high-density applications.
This diode supports a test current of 41.2 mA and maintains a low maximum reverse leakage current of 5 μA, which enhances its efficiency and reliability in power regulation circuits. It features a Zener impedance of 4 Ω, providing stable voltage across varying loads and temperatures.
Operating temperature ranges from -65°C to 150°C allows this diode to perform in harsh industrial, automotive, and commercial environments. The product complies with RoHS standards and is qualified to the AEC-Q101 automotive standard, guaranteeing high quality and automotive-grade reliability.
Typical applications include use as a voltage regulator and voltage reference in power supplies, industrial control, measurement instruments, and circuit protection. Its robust design and small package size make it ideal for space-constrained electronic designs that require precision voltage regulation.
The diode configuration is single with a nominal Zener voltage of 9.1 V. Maximum power dissipation is rated at 550 mW for efficient voltage regulation. The package type is DO-214AA, suitable for surface mounting applications.
Maximum reverse leakage current is limited to 5 μA ensuring low standby power consumption. Operating temperature range is from -65°C to 150°C. Meets RoHS compliance and automotive AEC-Q101 standard. Compact dimensions with a length of 5.6 mm and height of 2.47 mm.
