DiodesZetex Silicon Junction Switching Diode Surface Mount SMA Package 1 A Forward Current 800 V Reverse Voltage US1K-13-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex Silicon Junction Switching Diode Surface Mount SMA Package 1 A Forward Current 800 V Reverse Voltage US1K-13-F

Name: DiodesZetex Silicon Junction Switching Diode Surface Mount SMA Package 1 A Forward Current 800 V Reverse Voltage US1K-13-F
Brand: DiodesZetex
SKU: 129722
Price: 0.21 USD
Availability: InStock



Category Switching Diodes Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	2.1mm
Length	4.6mm
Model	US1K-13-F
Width	2.92mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SMA
Sub Type	Silicon Junction
Minimum Operating Temperature	-65°C
Pin Count	2
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	30A
Maximum Forward Voltage Vf	1.7V
Peak Reverse Recovery Time trr	75ns
Maximum Forward Current If	1A
Maximum Peak Reverse Repetitive Voltage Vrrm	800V

Key Features

Single diode configuration suitable for switching applications.
Surface mount SMA package ensures compact PCB integration.
Maximum forward current rating of 1 ampere for reliable operation.
Peak reverse repetitive voltage is 800 volts for high voltage performance.
Low forward voltage drop of 1.7 volts for efficient switching.
Fast peak reverse recovery time of 75 nanoseconds reduces switching losses.
Wide operating temperature range from -65°C to 150°C for harsh environments.
Peak non-repetitive forward surge current rating of 30 amperes for transient handling.

Product Description

DiodesZetex US1K-13-F is a silicon junction switching diode configured as a single diode in a surface mount SMA package, designed for efficient power switching and rectification.

Rated for a maximum forward current of 1 ampere and able to withstand a peak reverse repetitive voltage of 800 volts, this diode supports a broad range of electronic and power applications including industrial automation, power supplies, and telecommunications equipment.

The device has a low forward voltage drop of 1.7 volts and a fast peak reverse recovery time of 75 nanoseconds, which enhances overall switching performance and reduces energy loss in high-speed circuits.

Its measurable compact size with length 4.6 mm, width 2.92 mm, and height 2.1 mm allows for dense PCB layouts. The diode operates reliably over a wide temperature range from -65°C to 150°C, ensuring functionality in demanding environments.

With a peak non-repetitive forward surge current rating of 30 amperes, the diode can handle transient current spikes, making it suitable for robust industrial and automotive electronics, though it does not conform to automotive standards.

Ideal for use in electronic components, power connectors, and semiconductor devices, the US1K-13-F switching diode provides dependable performance in electrical and electronic manufacturing sectors.

Single diode configuration suitable for switching applications. Surface mount SMA package ensures compact PCB integration. Maximum forward current rating of 1 ampere for reliable operation. Peak reverse repetitive voltage is 800 volts for high voltage performance.

Low forward voltage drop of 1.7 volts for efficient switching. Fast peak reverse recovery time of 75 nanoseconds reduces switching losses. Wide operating temperature range from -65°C to 150°C for harsh environments. Compact dimensions: length 4.6 mm, width 2.92 mm, height 2.1 mm.

Peak non-repetitive forward surge current rating of 30 amperes for transient handling. Automotive standard compliance is not applicable. Explore more Switching Diodes and semiconductors from DiodesZetex on EnvMart to enhance your industrial and electronic projects.
