| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 3mm |
| Model | BZX84C3V3-7-F |
| Mount Type | Surface |
| Series | BZX84C3V3 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 350mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 3.3V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 600Ω |
| Typical Voltage Temperature Coefficient | -1.75mV/°C |
| Surface Mount case | SOT-23 |
DiodesZetex BZX84C3V3-7-F is a single Zener diode designed for voltage regulation purposes. It features a nominal Zener voltage of 3.3 V with a tolerance of 6%, and a maximum power dissipation rating of 350 mW. Packaged in a 3-pin SOT-23 surface mount case, the diode is ideal for compact electronics and circuit board applications.
The device operates efficiently within a temperature range of -65°C to 150°C, making it suitable for various industrial, automotive, and consumer electronics environments. It provides a maximum reverse leakage current of 5 μA and a low maximum Zener impedance of 600 Ω, ensuring stable voltage regulation under test conditions with a test current of 5 mA.
This Zener diode complies with the automotive standard AEC-Q101, which guarantees reliable performance in automotive and harsh conditions. Its typical voltage temperature coefficient of -1.75 mV/°C helps maintain consistent operating characteristics over a range of temperatures.
Compact in size with a length of 3 mm and height of 1 mm, this surface mount 3-pin diode is optimized for space-constrained applications in electronics manufacturing and PCB assembly. It is suitable for use in industries such as electrical equipment manufacturing, industrial electronics, automotive electronics, and power supply regulation systems.
Nominal Zener voltage of 3.3 V with ±6% tolerance. Maximum power dissipation of 350 mW for low power applications. Small footprint SOT-23 3-pin surface mount case. Low reverse leakage current of 5 μA for improved efficiency.
Wide operating temperature range of -65°C to 150°C. Compliant with automotive standard AEC-Q101 for reliability. Stable voltage regulation with 600 Ω maximum impedance. Typical voltage temperature coefficient of -1.75 mV/°C.
Suitable for industrial, automotive, and consumer electronics. Compact size allows efficient PCB layout and production. Explore more Zener Diodes and semiconductor products on EnvMart for your electronic design and manufacturing needs.
