DiodesZetex 8.2 V 500 mW Zener Diode Single 6% Tolerance Surface Mount 2-Pin SOD-123 BZT52C8V2-7-F

DiodesZetex BZT52C8V2-7-F is a high-quality 8.2 V Zener diode with a maximum power dissipation of 500 mW, designed for precise voltage regulation and stabilization in electronic circuits. Packaged in a compact surface mount SOD-123 2-pin case, this single-element Zener diode offers efficient space utilization on printed circuit boards, making it ideal for compact and low-power electronic designs.

This diode operates reliably over a wide temperature range from -65°C up to 150°C, suitable for industrial, automotive, and consumer electronics applications. The device features a voltage regulation tolerance of 6%, guaranteeing controlled voltage behavior at the nominal test current of 5 mA. Its maximum Zener impedance of 80 Ω contributes to stable voltage regulation while the maximum reverse leakage current is maintained at a low 700 nA to reduce power losses.

Certified to the automotive standard AEC-Q101, the BZT52C8V2-7-F diode ensures enhanced durability and quality for automotive electronic circuits requiring reliable voltage clamping and protection. Its typical voltage temperature coefficient of 4.7 mV/°C allows for predictable changes in Zener voltage with varying temperature, helping in accurate circuit design.

The diode measures 3.85 mm in length and 1.45 mm in height, facilitating surface mounting with minimal board space consumption. This product is manufactured in China and belongs to the BZT52C series, well recognized for quality and performance in the semiconductor market.

Nominal Zener voltage of 8.2 V for voltage regulation. Maximum power dissipation of 500 mW suitable for low power uses. Surface mount 2-pin SOD-123 package for compact PCB layout. Wide operating temperature range from -65°C to 150°C.

Maximum Zener impedance of 80 Ω ensures stable voltage. Low maximum reverse leakage current of 700 nA. Automotive certified to AEC-Q101 standard. Voltage temperature coefficient of 4.7 mV/°C for reliable thermal performance.

Compact size with length 3.85 mm and height 1.45 mm.

This Zener diode is suitable for use in industrial, automotive, laboratory, and consumer electronics applications where precise voltage control and protection are critical. Explore further semiconductor and Zener diode products on EnvMart for comprehensive sourcing and solutions.
