| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.43mm |
| Length | 3.1mm |
| Model | BZX84C8V2-E3-08 |
| Mount Type | Surface |
| Series | BZX84 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 700nA |
| Nominal Zener Voltage Vz | 8.2V |
| Zener Type | Small Signal |
| Maximum Zener Impedance | 15Ω |
| Surface Mount case | SOT-23 |
Vishay BZX84C8V2-E3-08 is a small signal Zener diode designed to provide reliable voltage regulation with a nominal Zener voltage of 8.2 V. Housed in a compact surface mount SOT-23 3-pin package, this device supports a maximum power dissipation of 300 mW making it suitable for low power electronic circuits.
The diode operates with a test current of 5 mA and has a Zener voltage tolerance of ±5%, allowing for consistent voltage regulation. With a maximum Zener impedance of 15 Ω, it offers stable voltage clamping and minimal voltage variation under varying current conditions.
The device features a maximum reverse leakage current of 700 nA and wide operating temperature range from -65 °C to 150 °C ensuring dependable operation in both industrial and automotive environments. Its single element chip configuration is optimized for discrete component use in electronic circuits requiring voltage reference or protection.
Typical applications include voltage stabilization in power supplies, clipping and limiting circuits in communication devices, and use in sensitive instrumentation requiring precision voltage regulation. The SOT-23 form factor supports high-density PCB layouts and assembly efficiency.
This Zener diode does not carry specific automotive or industrial approvals but complies with standard electronic component directives. It is a product of the well-established Vishay brand known for high-quality semiconductor components.
This diode has a nominal Zener voltage of 8.2 V with ±5% tolerance. Maximum power dissipation of 300 mW suitable for low power applications. Surface mount SOT-23 package with 3 pins for compact PCB designs. Maximum reverse leakage current of 700 nA for low leakage currents.
Operating temperature range from -65 °C to 150 °C for reliable performance. Test current of 5 mA ensuring stable voltage regulation. Single element chip configuration ideal for discrete voltage regulation. Compatible with industrial, laboratory, electronics manufacturing, and power supply applications.
