Molex 4-Way IDC Connector Female for Surface Mount, 1 Row, 250V AC, 1.2A Current, Picoflex Series 90816-0004

Molex 90816-0004 is a 4-Way IDC Connector Female designed for surface mount PCB applications. The single row connector provides reliable wire-to-board connections operating up to 250V AC and 1.2A current. It is part of the Picoflex series renowned for space-saving high-density configurations suitable for automotive and consumer electronics industries.

The connector features a 1.27mm pitch with an unshrouded design, brass contacts plated with tin to ensure excellent conductivity and corrosion resistance, coupled with a robust polyphthalamide housing for durability. This design supports operating temperatures from -40°C to 105°C, making it reliable under harsh environmental conditions.

Additional engineering design includes positive latch mechanisms for increased retention and polarized side posts with PC pegs to ensure proper orientation and mating. Its low-profile mated height optimizes space on printed circuit boards where compactness is crucial.

The product’s termination type is solder, facilitating secure and efficient PCB mounting. Manufactured in Ireland, this component complies with industrial quality standards, though it does not carry specific certifications.

Molex's Picoflex Series connectors save approximately 50% space compared with traditional pitch connectors and offer high resistance to vibration and shock, advancing product reliability in demanding applications. These connectors are widely used in automotive, consumer electronics, and industrial electronic assemblies.

Operates at 250V AC and 1.2A current rating. 1.27mm pitch with unshrouded female contacts. Brass contacts plated with tin for enhanced durability. Polyphthalamide housing material provides chemical and heat resistance. Temperature range from -40°C to 105°C supports harsh environments.

Includes positive latch and polarized side posts for secure and accurate mating. Part of space-saving Picoflex Series for high-density applications. Surface mount solder termination for stable PCB mounting. Manufactured in Ireland with high-quality standards.

Consider Molex IDC Connectors for your electronic component assemblies requiring reliable wire-to-board connections with compact form factor and high environmental resistance. Browse more IDC Connectors and related Molex products on EnvMart for comprehensive solutions in electronic and electrical assemblies.
