onsemi Operational Amplifier Dual Channel 16 MHz Gain Bandwidth 8-Pin SOIC MC33078DR2G

onsemi MC33078DR2G is a dual channel operational amplifier designed using bipolar technology optimized for audio and data signal processing applications. It features a high gain bandwidth product of 16 MHz and a low noise design using high frequency PNP input transistors, making it ideal for high fidelity amplification needs.

This device comes in an 8-pin SOIC surface mount package with compact dimensions (5 mm length, 4 mm width, 1.5 mm height) suitable for space-constrained electronic circuits. It supports dual supply voltage operation from ±5 V to ±18 V, accommodating a wide variety of industrial and commercial circuit designs.

The MC33078DR2G offers low input offset voltage of 0.15 mV, low total harmonic distortion at 0.002%, and a high slew rate of 7 V/μs, enabling precise and fast signal amplification. The large output voltage swing (+14.1 V / -14.6 V) and output current capability of 29 mA allow driving loads directly. With an operating temperature range from -40°C to 85°C, this amplifier is suitable for harsh industrial, automotive, and commercial environments.

Additional features include input bias currents of 750 nA and offset current of 150 nA, ensuring minimal signal distortion and offset errors. The device is manufactured in the Philippines and offers excellent frequency stability and ESD protection at the input stage.

Dual channel operational amplifier with low noise suitable for audio and data signal processing. Gain bandwidth product of 16 MHz ensures high frequency response. Surface mount SOIC package with 8 pins for compact circuit design.

Wide supply voltage range with ±5 V to ±18 V dual supply operation. Low input offset voltage and low total harmonic distortion for accurate amplification. High slew rate of 7 V/μs supports fast signal changes. Operating temperature range from -40°C to 85°C for industrial applications.

Input bias current of 750 nA and offset current of 150 nA for precision performance. Maximum output current of 29 mA with large output voltage swing. Compact dimensions: Length 5 mm, Width 4 mm, Height 1.5 mm.

This Operational Amplifier is well-suited for use in industrial electronics, audio equipment, data acquisition systems, communications, and instrumentation. Its reliable performance and wide operating conditions make it a versatile component for electronic designs requiring stable and precise amplification.
