onsemi Operational Amplifier 14-Pin SOIC 32V Quad Channels LM2902DR2G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 8.75mm |
| Model | LM2902DR2G |
| Width | 4mm |
| Mount Type | Surface |
| Series | LM2902 |
| Output Current | 40mA |
| Maximum Operating Temperature | 105°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 32V |
| Minimum Supply Voltage | 5V |
| Input Bias Current | -250 nA |
| Vos - Input Offset Voltage | 7 mV |
| Input Offset Current | 50 nA |
| Low Input Bias Currents | 100 nA Maximum (LM324A) |
| Single Supply Operation | 3 V to 32 V |
Key Features
- Includes four independent operational amplifiers in one SOIC package.
- Operates from a single supply voltage range from 3 V to 32 V.
- Input bias current of -250 nA enhances precision performance.
- Wide operating temperature range from -40°C to 105°C suitable for harsh environments.
- 14-pin SOIC surface mount package for compact PCB layouts.
- Outputs can drive loads with a current up to 40 mA.
- Input offset voltage of 7 mV and input offset current of 50 nA for accurate amplification.
- Complies with automotive standard AEC-Q100 ensuring reliability in automotive applications.
Product Description
onsemi LM2902DR2G is a quad operational amplifier designed for industrial, automotive, and electronic applications requiring precise amplification and reliability. Packaged in a 14-pin SOIC surface mount format, this device supports a broad supply voltage range from 3 V up to 32 V, enabling use in various single supply operations. Its input bias current of -250 nA and input offset voltage of 7 mV provide high accuracy signal processing.
The LM2902DR2G features four independent amplifiers that include true differential inputs, eliminating the necessity for external biasing in many use cases. The output voltage range includes the negative power supply voltage, facilitating flexible circuit design. The device is capable of driving loads with output currents up to 40 mA, suitable for moderate power applications.
Designed to operate under extended temperature conditions (-40°C to 105°C), this amplifier meets the AEC-Q100 automotive standard, offering enhanced robustness for automotive electronics. Short circuit protected outputs and ESD clamps on inputs further improve the device's ruggedness, ensuring stable operation in harsh environments.
With a height of 1.5 mm, length of 8.75 mm, and width of 4 mm, the SOIC package minimizes PCB space usage while maintaining ease of mounting. The LM2902 series integrates internal compensation for stable performance across the operating range.
Four amplifiers per package for multi-channel designs. True differential input stage provides precise signal processing. Short circuit protected outputs enhance device durability. Single supply operation supports 3 V to 32 V voltage ranges.
Low input bias currents and offset voltages improve accuracy. Automotive standard AEC-Q100 compliance guarantees high reliability. Compact SOIC packaging suitable for space-limited applications. Ideal for industrial, automotive, laboratory, and consumer electronics uses.
Internal ESD protection ensures robust handling and operation.
This operational amplifier is well suited to a variety of environments including industrial controls, automotive sensor systems, consumer electronics, and laboratory instrumentation. Explore more from the onsemi Operational Amplifier range at EnvMart, your trusted electronics components source.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This operational amplifier operates from a single supply voltage range of 3 V to 32 V.
It includes four independent operational amplifiers in one package, providing four channels.
The LM2902DR2G can drive loads with an output current of up to 40 mA.
This operational amplifier has a height of 1.5 mm, length of 8.75 mm, and width of 4 mm.
The input offset voltage is specified at 7 mV, which contributes to its accuracy in amplification.
It operates within a temperature range of -40°C to 105°C, making it suitable for harsh environments.
Yes, it complies with the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
The input bias current is -250 nA, which enhances its precision performance.
It is packaged in a 14-pin SOIC surface mount format, suitable for compact PCB layouts.
This operational amplifier is well suited for industrial controls, automotive sensor systems, consumer electronics, and laboratory instrumentation.
The outputs are short circuit protected, enhancing the device's durability during operation.
The input offset current is specified at 50 nA, which contributes to its overall accuracy.
