Molex 20-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A, 250V, Tin over Nickel Plating 90814-0820

The Molex 90814-0820 is a 20-way IDC connector with a male configuration designed for surface mounting on printed circuit boards. This connector is part of the Picoflex series which features a 1.27 mm pitch and a single row of contacts, making it ideal for high-density electronic applications where space optimization is critical.

Constructed from brass contacts plated with tin over nickel and housed in nylon, the connector offers excellent electrical conductivity combined with durability. It supports a current rating of 1.2A and voltage rating of 250V AC, and is engineered to operate reliably between temperatures of -40°C and 105°C.

The IDC termination technology allows for quick and solderless wire assembly, significantly enhancing production efficiency and reducing assembly errors. Its unshrouded male contact design and straight orientation make it suitable for a wide variety of electronic devices in automotive and consumer electronics sectors.

Designed to withstand vibration and shock, the Picoflex IDC connector range from Molex ensures stable and secure connections in demanding environments. The low mated height profile of just 6.4 mm contributes to compact system design.

This connector complies with UL (E29179) and CSA (LR19980-181) safety approvals, endorsing its quality and adherence to industry standards. Features a single row with 20 contacts ensuring compact high-density wiring. Offers straight orientation with an unshrouded male connector type for versatile PCB integration.

Constructed with brass contacts plated with tin over nickel for corrosion resistance and conductivity. Housing is made of durable nylon material offering mechanical stability and insulation. Designed for operation across a temperature range of -40°C to 105°C suitable for demanding environments.

Utilizes IDC termination for fast and efficient wire connections without soldering. The 1.27 mm pitch Picoflex series delivers space-saving benefits with a low profile and vibration resistance. Ideal for automotive, consumer electronics, and other industrial applications requiring robust wire-to-board connections.

Connector complies with UL and CSA safety approvals, ensuring quality and safety standards. Explore a wide range of IDC Connectors and other electronic components available to support your industrial, automotive, and consumer electronics projects at EnvMart.
