Molex 26-Way IDC Connector Female for Cable, 2 Row, 1.2A Current, 250V AC, Right Angle Orientation 90327-0326
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1.2A |
| Mount Type | Cable |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 26 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Right angle orientation for optimal cable positioning and routing.
- Unshrouded connector design with female gender contacts.
- Phosphor bronze contacts plated with tin over nickel for enhanced conductivity and corrosion resistance.
- Polyethylene Terephthalate housing with UL94V-0 flame retardant rating.
- Operational temperature range from -40°C to 105°C for reliability.
- Insulation Displacement Contact (IDC) termination for secure cable connection.
- 4 point contact design ensures connection reliability under vibration and shock.
- 1.27mm pitch providing 50% space saving compared with traditional connectors.
Product Description
Molex 90327-0326 IDC Connector Female for Cable is a high-density electronic component designed for effective wire-to-board connections in automotive, consumer electronics, and industrial applications. Featuring 26 contacts arranged in 2 rows and a pitch of 1.27mm, this right angle connector supports a current of 1.2A and voltage rating of 250V AC.
The connector features unshrouded female contacts made from phosphor bronze plated with tin over nickel to ensure superior electrical conductivity and corrosion resistance. The housing uses durable Polyethylene Terephthalate material compliant with UL94V-0 flame retardant standards.
The insulation displacement contact (IDC) termination type allows precise and secure cable connections with 4 point contact design enhancing reliability under vibration and shock conditions. The product operates reliably between a minimum temperature of -40°C and a maximum temperature of 105°C.
This Picoflex series connector provides 50% space savings over traditional pitch connectors, and its low mated height of only 6.4mm allows compact assembly designs. The connector's integral strain relief and excellent polarisation features improve service life and installation ease.
Right angle orientation and cable mount type for flexible installation options. Suitable for wire-to-board applications in automotive, industrial, and consumer electronic sectors. Meets UL (E29179) and CSA (LR19980-181) approvals ensuring safety and industry compliance.
Unshrouded design allows easy inspection and maintenance. High resistance to vibration and shock enhances durability in harsh environments.
Overall, the Molex 90327-0326 IDC Connector Female is engineered to provide dependable, compact, and efficient electrical connections in demanding applications, making it a preferred choice in the electronics component market.
Explore additional IDC Connectors and related electronics components at EnvMart for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector has a current rating of 1.2A.
The voltage rating for the Molex 90327-0326 is 250V AC.
The pitch of the contacts in this connector is 1.27mm.
This connector operates reliably within a temperature range of -40°C to 105°C.
The Molex 90327-0326 features 26 contacts arranged in 2 rows.
The housing is made from Polyethylene Terephthalate, and the contacts are made from phosphor bronze plated with tin over nickel.
It uses Insulation Displacement Contact (IDC) termination for secure cable connections.
This connector has a right angle orientation, allowing for optimal cable positioning and routing.
Yes, the 4 point contact design enhances connection reliability under vibration and shock conditions.
The contacts in the Molex 90327-0326 are female.
Yes, it meets UL (E29179) and CSA (LR19980-181) approvals, ensuring safety and compliance with industry standards.
The weight of this connector is not specified in the provided data.
