Molex KK 396 Series Right Angle Through Hole Pin Header 3 Contacts 3.96 mm Pitch 1 Row Unshrouded 26-60-5030
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Phosphor Bronze |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.96mm |
Key Features
- Rated for 7A current capacity.
- Housing made from durable polyester material.
- Right angle orientation suitable for wire-to-board connections.
- Contact material is phosphor bronze plated with tin for reliable conductivity.
- Terminated by soldering with through hole mount type.
- Operates between -40°C to 105°C temperature range.
- Supports 250V maximum voltage rating.
- Tail pin length and row pitch are both 3.96 mm.
Product Description
Molex 26-60-5030 KK 396 Series Right Angle Through Hole Pin Header is meticulously designed to provide reliable wire-to-board connections in electronic assemblies. This product features 3 male contacts arranged in a single row with a precise 3.96 mm pitch ensuring consistent spacing suitable for various PCB designs.
The housing is crafted from robust polyester material granting enhanced durability and insulation under industrial operating conditions. Contacts are made from phosphor bronze and plated with tin to ensure excellent conductivity and resistance to corrosion.
The pin header is intended for through hole mounting and is terminated by soldering, providing a stable and secure mechanical and electrical interface with PCBs. Its right angle orientation facilitates compact assembly layouts minimizing PCB footprint.
Designed to operate within a temperature range of -40°C to 105°C, it can withstand harsh operating environments found in industrial and electronic applications. Rated current capacity of 7A supports moderate power loads.
Unshrouded design allows compatibility with multiple mating connectors including 2139, 3069, 6442, and 41695 Series housings. Offers a maximum voltage rating of 250V suitable for a wide range of electronic devices. The tail pin length and row pitch of 3.96 mm facilitate easy integration into standard PCB layouts.
This pin header is ideal for use in manufacturing, industrial equipment, and electronic device assembly, where reliable connector performance is critical. Explore the broad range of Molex KK series connectors on EnvMart for advanced electronic component solutions.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a current capacity of 7A.
The maximum voltage rating is 250V.
It operates within a temperature range of -40°C to 105°C.
This model uses through hole mounting and is terminated by soldering.
The housing is made from durable polyester, while the contacts are made from phosphor bronze plated with tin.
It features 3 male contacts arranged in a single row.
The pitch of the contacts is 3.96 mm.
This pin header is unshrouded, allowing compatibility with multiple mating connectors.
The tail pin length is 3.96 mm.
It is ideal for use in manufacturing, industrial equipment, and electronic device assembly.
This model belongs to the Molex KK 396 series.
The country of origin for this pin header is India.
