Wurth Elektronik 2813 Shielded Wirewound Surface Mount Inductor 10 μH ±30% 750 mA WE-TPC 744029100
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 2.78mm |
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 1.35mm |
| Length | 2.8mm |
| Depth | 2.8mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 10μH |
| Package/Case | 2813 |
| Maximum DC Current | 750mA |
| Maximum DC Resistance | 470mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 40MHz |
| Inductor Construction | Wirewound |
| Standards/Approvals REACH, JEDEC JS709B, RoHS, IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E |
Key Features
- This surface mount inductor features a compact 2813 package case for efficient PCB layout.
- The magnetic shielding minimizes leakage fields for better electromagnetic compatibility.
- Constructed with a ferrite core and wirewound design for stability and reliability.
- Operates reliably within a temperature range of -40°C to 125°C.
- Maximum DC resistance is 470 mΩ to ensure low energy loss during operation.
- Suitable for portable power applications including PDAs, digital cameras, and embedded PCs.
- Meets strict standards such as REACH, RoHS, and JEDEC JS709B for quality and compliance.
- Self-resonant frequency of 40 MHz supports high-frequency electronic circuits.
Product Description
The Wurth Elektronik 744029100 WE-TPC series is a highly reliable shielded wirewound Surface Mount Inductor designed with a ferrite core, offering an inductance of 10 μH ±30% and a maximum DC current rating of 750 mA. Its compact 2813 package with dimensions of approximately 2.8 mm length, 2.78 mm diameter, and 1.35 mm height makes it ideal for modern compact electronics requiring efficient power management.
Engineered to operate in harsh conditions, this component supports an operating temperature range from -40°C to 125°C. The magnetic shielding significantly reduces electromagnetic interference, ensuring enhanced performance in densely packed boards and circuits. The maximum DC resistance of 470 mΩ contributes to minimal power loss and improved efficiency.
The wirewound construction with a ferrite core ensures stable inductance and durability, suitable for various applications such as portable power devices (PDAs, digital cameras), DC/DC converters, embedded PCs, and telemetry systems. It complies with stringent quality and environmental standards including REACH, RoHS, IEC, and JEDEC, guaranteeing safe and reliable use in automotive and industrial contexts.
This inductor is packaged in tape & reel format, supporting automated pick-and-place manufacturing processes common in electronics production lines. It supports a self-resonant frequency up to 40 MHz, making it suitable for high-frequency electrical circuits and devices.
The WE-TPC series is notable for its extremely flat profile combined with high current handling capability. Applications include portable power supplies, embedded systems, and telemetric devices. The ferrite core and magnetic shielding contribute to performance stability and low EMI.
Compliance with international standards ensures interoperability and safety. Explore a range of high-quality inductors and passive components at EnvMart for your industrial, commercial, or electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 10 μH ±30%.
It has a maximum DC current rating of 750 mA.
The dimensions of the 2813 package are approximately 2.8 mm in length, 2.78 mm in diameter, and 1.35 mm in height.
This model operates reliably within a temperature range of -40°C to 125°C.
The maximum DC resistance is 470 mΩ, which helps ensure low energy loss during operation.
The inductor is constructed with a ferrite core.
It has a maximum self-resonant frequency of 40 MHz, making it suitable for high-frequency applications.
It is packaged in tape & reel format, supporting automated pick-and-place manufacturing processes.
It meets strict standards including REACH, RoHS, JEDEC JS709B, and IEC 60286-3.
The inductor features a wirewound construction, which contributes to its stability and reliability.
It is suitable for portable power applications, including PDAs, digital cameras, and embedded PCs.
The magnetic shielding minimizes leakage fields, enhancing electromagnetic compatibility and performance in densely packed circuits.
