Wurth Elektronik Wirewound Surface Mount Inductor WE-PD2 10μH ±10 % 2.3A Idc Ferrite Core 74477510

Wurth Elektronik 74477510 Wirewound Surface Mount Inductor WE-PD2 series features a 10μH inductance with ±10 % tolerance and a ferrite core construction. Designed for high efficiency in switching regulator applications including computers, laptops, mobile phones, and integrated DC/DC converters, this inductor supports a maximum DC current of 2.3 A.

With compact physical dimensions of 7.8 mm length, 7 mm depth, and 5 mm height, it is suitable for space-constrained electronic components assemblies. The inductor operates reliably across a temperature range from -40°C to 125°C, meeting automotive standard AEC-Q200 to ensure performance and durability in demanding environments.

The wirewound construction provides stable inductance and a low maximum DC resistance of 70 mΩ, reducing power losses during operation. Its maximum self-resonant frequency of 23 MHz makes it appropriate for high-frequency switching regulator circuits. The open frame design is unshielded, facilitating its use where minimal magnetic interference is required.

Packaged on tape and reel, this surface mount component is optimized for automated production assembly processes, improving manufacturing efficiency. The product complies with RoHS regulations, supporting environmentally responsible manufacturing.

Constructed with a ferrite core and wirewound technology for reliable inductance. Rated maximum DC current of 2.3 A for effective power handling. Compact dimensions of 7.8 mm length, 7 mm depth, and 5 mm height. Operates within temperature range -40°C to 125°C.

RoHS compliant and suitable for surface mount applications with tape and reel packaging. Maximum DC resistance of 70 mΩ ensures low power loss. Maximum self-resonant frequency of 23 MHz for high-frequency applications. Meets automotive standard AEC-Q200 ensuring durability and quality.

Shielding is not provided, enabling open frame SMD power inductor design.

This Wurth Elektronik WE-PD2 inductor is ideal for industrial electronics manufacturing, telecommunications, computing devices, automotive electronics, and power supply circuits. Its specifications ensure reliable performance in various high-efficiency switching regulator and DC/DC converter applications.
