Wurth Elektronik WE-FAMI 1215 Shielded Wirewound Surface Mount Inductor, Ferrite Core, 22 μH ±20%, 6.9 A, 1215 744750460220
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 12.8mm |
| Brand | Wurth Elektronik |
| Height | 15.8mm |
| Length | 21.3mm |
| Depth | 5.5mm |
| Packaging | Tape & Reel |
| Series | WE-FAMI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | JEDEC JS709B, IEC 61249-2-21, REACH, RoHS |
| Package/Case | 1215 |
| Maximum DC Current | 6.9A |
| Pin Count | 2 |
| Maximum DC Resistance | 16mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Inductor Construction | Wirewound |
Key Features
- Inductance value of 22 μH with ±20% tolerance.
- Shielded wirewound construction reduces stray magnetic field.
- Ferrite core ensures reliable and stable inductor performance.
- Maximum DC current supported is 6.9 A for robust electronic circuits.
- Low DC resistance of 16 mΩ enhances efficiency.
- Surface mount design (1215 package) suitable for automated assembly.
- Wide operating temperature range from -40°C to 125°C.
- Compliance with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards.
Product Description
Wurth Elektronik 744750460220 WE-FAMI Series shielded wirewound surface mount inductor is engineered for high-performance electronics, offering 22 μH inductance with a ±20% tolerance and maximum DC current handling of 6.9 A. Featuring a ferrite core, this component delivers optimal magnetic shielding and saturation current, making it ideal for circuits requiring high stability and low stray field.
The inductor is designed in the 1215 package and supports tape & reel packaging for efficient automated surface mount assembly. The wirewound construction enhances both electrical and mechanical stability, ensuring long-term reliability even under demanding conditions. Its low DC resistance of 16 mΩ means minimal energy losses, contributing to system efficiency.
This product incorporates two solder terminals and is compliant with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards. The ferrite material core further reduces losses and supports high-frequency operation, making it suitable for applications like DC-DC converters, battery chargers, power supplies, computer systems, and portable electronic equipment.
It boasts a broad operating temperature range from -40°C to 125°C, with robust shielded design that optimizes performance and reduces electromagnetic interference. The moulded wirewound structure aids reliability and mechanical strength.
Key use cases include industrial control solutions, laboratory electronics, commercial power conversion, and demanding home entertainment systems, among others. Explore EnvMart's full range of Wurth Elektronik Inductors and Electronics Components to discover solutions tailored to industrial, laboratory, and precision circuit requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 22 μH with a tolerance of ±20%.
The maximum DC current supported by this inductor is 6.9 A.
The inductor has a diameter of 12.8 mm, height of 15.8 mm, length of 21.3 mm, and depth of 5.5 mm.
This inductor features a ferrite core, which aids in reducing losses and supporting high-frequency operation.
It operates within a temperature range of -40°C to 125°C.
The inductor is constructed using a wirewound design, which enhances both electrical and mechanical stability.
It complies with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards.
The maximum DC resistance is 16 mΩ, contributing to minimal energy losses.
This model is packaged in tape & reel format, suitable for automated surface mount assembly.
This inductor has a pin count of 2.
It is suitable for applications such as DC-DC converters, battery chargers, power supplies, and portable electronic equipment.
The termination style for this inductor is solder, allowing for secure connections.
