Bourns 100 mH Ferrite Leaded Inductor 9A 82Ω RL181S
Specifications
| Country of Origin | China |
|---|---|
| Diameter | 10.5mm |
| Brand | Bourns |
| Height | 14mm |
| Length | 19mm |
| Model | RL181S |
| Depth | 14mm |
| Packaging | 100 pieces |
| Mount Type | Through Hole |
| Series | RL181S |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Test Frequency | 50kHz |
| Core Material | Ferrite |
| Inductance | 100mH |
| Standards/Approvals | RoHS |
| Maximum DC Current | 9A |
| Maximum DC Resistance | 82Ω |
| Inductance Tolerance | 10 % |
| Termination Style | Radial Lead |
| Maximum Self Resonant Frequency | 900kHz |
| Minimum Quality Factor | 15 |
| Lead Pitch | 5mm |
| Lead Diameter | 0.7mm |
| Bourns 100 mH Ferrite Leaded Inductor, Max SRF | 900 kHz, Q:15, 9 A Idc, 82 Ω Rdc, RL181S |
Key Features
- Inductance of 100 mH for effective filtering and energy storage.
- Maximum DC current rating of 9A supports robust applications.
- Low DC resistance of 82 Ω enhances efficiency in circuits.
- Ferrite core material provides stable performance across temperature range.
- Lead diameter of 0.7 mm and radial lead termination ensure reliable mounting.
- Operable from -55°C to 105°C for broad environmental compatibility.
- Self-resonant frequency up to 900 kHz for high-frequency circuits.
- Quality factor (Q) minimum 15 for consistent inductive behavior.
Product Description
Bourns RL181S-104J-RC is a high-quality ferrite leaded inductor with 100 mH inductance, engineered for demanding electronic applications requiring precise performance, high current handling, and reliability. The device is suitable for power supplies, filters, and energy storage circuits where low DC resistance and high quality factor are essential.
The inductor's robust ferrite core enables stable operation over a wide temperature range from -55°C to 105°C, making it ideal for both industrial and commercial environments. Its maximum DC current capability of 9A ensures applicability in circuits requiring powerful inductive components. The low DC resistance of only 82 Ω supports efficient energy transfer and minimizes losses.
With a self-resonant frequency reaching 900 kHz, the RL181S-104J-RC is optimized for high-frequency circuit applications such as switching regulators and RF filtering. The radial lead termination style with 0.7 mm lead diameter and standard lead pitch facilitates reliable through-hole PCB mounting. Dimensions include a 10.5 mm diameter and 14 mm height, providing compact form factor suitable for dense layouts.
This series guarantees a minimum quality factor (Q) of 15, ensuring consistent and predictable inductor behavior under various loads. The 10% inductance tolerance provides additional assurance in meeting design requirements. The product is RoHS compliant and adheres to modern electronic standards, supporting environmentally conscious designs.
Inductance of 100 mH and maximum DC current rating of 9A. Ferrite core material for reliable performance and low EMI. Radial lead style enables secure through-hole mounting. Wide temperature range suitable for industrial and commercial projects.
High self-resonant frequency for effective use in RF applications. RoHS compliant, supporting green technology initiatives. Packed in 100 piece boxes for convenient volume usage.
Common uses include industrial power supply filtering, laboratory electronics, manufacturing equipment, and high-frequency signal conditioning. Ideal for applications such as energy storage, EMI suppression, and precision filtering in diverse electronics environments.
Discover more Bourns inductors and passive electronic components in the Inductors section on EnvMart to support your precise design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has an inductance value of 100 mH, making it suitable for effective filtering and energy storage applications.
This model has a maximum DC current rating of 9A, which supports robust applications in various electronic circuits.
The inductor features a low DC resistance of 82 Ω, enhancing efficiency in circuit applications.
It operates within a temperature range of -55°C to 105°C, suitable for both industrial and commercial environments.
The maximum self-resonant frequency of this inductor is up to 900 kHz, making it suitable for high-frequency circuit applications.
This model guarantees a minimum quality factor (Q) of 15, ensuring consistent inductive behavior under various loads.
The inductor has a diameter of 10.5 mm, a height of 14 mm, and a length of 19 mm, providing a compact form factor for dense layouts.
It features a radial lead termination style, which facilitates reliable through-hole PCB mounting.
This inductor is packaged in boxes of 100 pieces, allowing for convenient volume usage in various applications.
Yes, this model is RoHS compliant, supporting environmentally conscious design initiatives.
It is commonly used in power supply filtering, energy storage, EMI suppression, and precision filtering in diverse electronics environments.
The lead diameter of this inductor is 0.7 mm, ensuring reliable mounting in PCB applications.
