| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.8mm |
| Length | 1.8mm |
| Model | PMEG2005EJ,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PMEG2005EJ |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323F |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10A |
| Maximum Forward Voltage Vf | 390mV |
| onsemi 30 V 1 A Schottky Barrier Diode Schottky 2-Pin SOD-323 NSR1020MW2T1GBrand | onsemi |
The Nexperia PMEG2005EJ,115 is a single Schottky diode designed for surface-mount applications requiring high efficiency and low forward voltage drop. This device is optimised for fast switching and minimal power losses, making it suitable for industrial electronics, telecommunications, and power management systems.
Encased in a compact 2-pin SOD-323F package, the diode offers robust electrical characteristics including a maximum continuous forward current of 500 mA and a peak reverse repetitive voltage rating of 20 V. It exhibits a minimal forward voltage drop of 390 mV and a peak surge current capability of 10 A, ensuring durability under transient conditions.
With an operating temperature range from -65°C to 150°C, the diode maintains performance reliability across harsh environmental conditions typical in industrial and commercial use. Its low capacitance and leakage current further enhance its suitability in switching power supplies and high-frequency applications.
Technical features include a 2-pin configuration compatible with surface mount technology, plus physical dimensions of 1.8 mm length, 1.35 mm width, and 0.8 mm height to support compact PCB designs.
Manufactured in China, this component is ideal for system designers seeking a high-efficiency Schottky diode for power rectification and protection in a small form factor. This diode offers a maximum continuous forward current of 500 mA.
It features a peak reverse repetitive voltage of 20 V. The package dimensions measure 1.8 mm length, 1.35 mm width, and 0.8 mm height. Designed to operate between -65°C to 150°C for temperature resilience. Equipped with low forward voltage of 390 mV and low leakage current for high efficiency.
Supports peak non-repetitive forward surge current up to 10 A. The diode configuration is single with a Schottky rectifier type for rapid switching. Pin count is 2 compliant with standard SOD-323F mounting. Manufactured in China with no automotive standard compliance.
Explore the Nexperia range at EnvMart for reliable semiconductor solutions suited to a variety of industrial and commercial electronics applications.
