Molex C-Grid III Series Straight Through Hole PCB Header, 30 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 90130-1230
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 30 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features 30 male contacts arranged in 2 rows for compact design.
- Utilizes 2.54 mm pitch and straight orientation for standard PCB mounting.
- Brass contact material with gold plating ensures excellent conductivity and corrosion resistance.
- Shrouded housing made from durable polyester protects contacts from damage.
- Rated for a current of 3 A and voltage up to 350 V for robust electrical performance.
- Suitable for through-hole soldering with tail pin length of 2.9 mm.
- Operates reliably between -55°C to 125°C for harsh industrial environments.
- Fully compliant with DIN 41651 and HE13/14 standards for connector interoperability.
Product Description
Molex 90130-1230 C-Grid III Series Straight Through Hole PCB Header features 30 male contacts across 2 rows with a 2.54 mm pitch, ideal for high-density wire-to-board applications in electronics and industrial sectors.
The connector housing is made from robust polyester and shrouded design minimizes mechanical damage risks during assembly. Brass contacts plated with gold ensure low resistance and long-term electrical integrity critical for power and signal transmission.
This PCB header supports a current rating of 3 A and voltage rating of 350 V, making it suitable for diverse electronic devices, machinery, and control systems operating under demanding conditions from -55°C up to 125°C.
The through-hole mounting with solder termination provides secure mechanical and electrical connection to printed circuit boards, enhancing reliability in industrial manufacturing, automation, and instrumentation.
Conforming to DIN 41651 and HE13/14 standards, this header ensures compatibility and interchangeability with locking housings within the Molex C-Grid III range. Features 30 male contacts arranged in 2 rows for compact design.
Utilizes 2.54 mm pitch and straight orientation for standard PCB mounting. Brass contact material with gold plating ensures excellent conductivity and corrosion resistance. Shrouded housing made from durable polyester protects contacts from damage.
Rated for a current of 3 A and voltage up to 350 V for robust electrical performance. Suitable for through-hole soldering with tail pin length of 2.9 mm. Operates reliably between -55°C to 125°C for harsh industrial environments.
Fully compliant with DIN 41651 and HE13/14 standards for connector interoperability.
This PCB Header is ideal for industrial, electronic manufacturing, automation, and laboratory equipment assembly requiring reliable, high-quality wire-to-board connections. Explore a wide range of Molex connectors and components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3 A and a voltage of up to 350 V, making it suitable for various electronic applications.
It features a 2.54 mm pitch with 30 male contacts arranged in 2 rows, designed for compact and efficient connections.
The housing is made from durable polyester, while the contacts are brass with gold plating to ensure excellent conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C, suitable for harsh industrial environments.
This unit utilizes through-hole mounting with solder termination, providing a secure mechanical and electrical connection to printed circuit boards.
Yes, it is fully compliant with DIN 41651 and HE13/14 standards, ensuring compatibility and interoperability with other connectors in the Molex C-Grid III range.
The tail pin length is 2.9 mm, designed for effective soldering to circuit boards.
The shrouded design protects the contacts from mechanical damage during assembly, enhancing reliability in use.
It uses a wire-to-board connector system, suitable for high-density wire connections in electronic applications.
The mating pin length is 6.75 mm, allowing for proper connection with compatible connectors.
This model is ideal for industrial, electronic manufacturing, automation, and laboratory equipment assembly that requires reliable wire-to-board connections.
The country of origin for this PCB header is India.
