onsemi Digital Transistor NPN 50 V Surface Mount SOT-23, 3-Pin MMUN2214LT1G

onsemi MMUN2214LT1G is a high-quality digital NPN transistor designed for surface mount technology applications. This device is presented in a compact SOT-23 package with three pins, enabling easy integration into modern PCB layouts requiring minimal space. It supports a maximum collector emitter voltage of 50 V and collector base voltage of 50 V, ensuring robust switching performance.

The integrated resistor feature distinguishes this transistor as a digital or bias resistor transistor, allowing it to be driven directly from digital sources without the need for additional external resistors. This simplification benefits design engineers by reducing component count and circuit complexity.

Rated for a power dissipation of up to 230 mW, the MMUN2214LT1G is suitable for moderate power applications within consumer electronics, automotive systems, and industrial control devices. Its minimum DC current gain of 80 provides reliable signal amplification and switching.

The small package dimensions of 2.9 mm by 1.3 mm by 0.94 mm make it ideal for compact electronic devices. The transistor's ability to operate at temperatures up to 150°C enhances its reliability under harsh conditions.

This transistor complies with the automotive standard AEC-Q101, signifying its qualification for automotive circuit designs requiring stringent quality and reliability standards. This device enables integration into various digital and bias resistor transistor circuits.

It supports robust voltage ratings suitable for multiple applications. The compact SOT-23 package optimizes board space utilization. High thermal tolerance permits use in demanding temperature environments. Compliance with AEC-Q101 ensures automotive-grade quality.

Ideal for industrial, automotive, consumer electronics, and precise digital switching applications, the onsemi MMUN2214LT1G digital transistor combines reliability and efficiency in a small footprint. Explore more semiconductor components and Digital Transistor options in EnvMart’s extensive catalog.
