STMicroelectronics 1200 V 15 A Surface Mount Switching Diode TO-263 Package STTH1512G

STMicroelectronics STTH1512G is a high voltage, high current switching diode designed for surface mount applications using the TO-263 package. This diode supports a maximum continuous forward current of 15 A and withstands a peak reverse repetitive voltage of 1200 V, making it suitable for power electronic circuits requiring efficient diode switching.

The device features a fast peak reverse recovery time of 105 ns and a low peak reverse current of 15 μA, resulting in effective switching with minimal losses. It operates reliably across a broad temperature range from -65°C to 175°C, allowing usage in industrial, automotive, and commercial electronic applications.

The STTH1512G has a maximum forward voltage drop of 2.1 V and can handle peak non-repetitive forward surge currents up to 200 A, which ensures durability against transient events. The 3-pin TO-263 package provides a compact footprint for surface mounting on printed circuit boards, optimizing space and thermal dissipation.

This switching diode is RoHS compliant and designed according to industry standards, prioritizing reliability and efficiency in switching power applications. Its dimensions include a height of 4.6 mm, a length of 10.4 mm, and a width of 9.35 mm, with a pin diameter of around 3.75 mm.

Ideal industrial use cases include power supply circuitry, rectifiers in inverters, power control modules, and switching power supplies. It is widely used in electronics manufacturing, automotive electronics, industrial automation, and electrical equipment design.

The STTH1512G diode enables engineers and designers to achieve efficient power management with robust performance under demanding operating conditions. Explore a broad range of semiconductor diodes and rectifiers to find the perfect match for your power electronics systems at EnvMart.

Maximum continuous forward current of 15 A ensures robust performance. Peak reverse repetitive voltage of 1200 V suitable for high voltage applications. Low peak reverse current of 15 μA aids in efficient switching. Fast peak reverse recovery time of 105 ns for rapid switching cycles.

Wide operating temperature range from -65°C to 175°C for versatility in harsh environments. Compact TO-263 surface-mount package with 3 pins for easy PCB integration. Maximum forward voltage drop of 2.1 V to minimize power losses.

Peak non-repetitive forward surge current of 200 A for transient handling.
