STMicroelectronics Schottky Diode 60 V 500 mA Surface Mount 2-Pin SOD-123 STPS0560Z

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Schottky Diode 60 V 500 mA Surface Mount 2-Pin SOD-123 STPS0560Z

Name: STMicroelectronics Schottky Diode 60 V 500 mA Surface Mount 2-Pin SOD-123 STPS0560Z
Brand: STMicroelectronics
SKU: 116456
Price: 0.09 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.35mm
Length	2.85mm
Model	STPS0560Z
Width	1.7mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	500mA
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	50μA
Peak Non-Repetitive Forward Surge Current Ifsm	5.5A
Maximum Forward Voltage Vf	0.5V
onsemi 60V 2A, Schottky Diode, 2-Pin SOD-123FL NTS260SFGBrand	onsemi

Key Features

Features a maximum continuous forward current of 500 mA for reliable performance.
Offers a peak reverse repetitive voltage of 60 V suitable for diverse electronic circuits.
Compact 2.85 mm length, 1.7 mm width, and 1.35 mm height dimensions for space-saving PCB layouts.
Supports a peak non-repetitive forward surge current of 5.5 A for transient handling.
Operates effectively within a temperature range from -65°C to 150°C.
Designed with low forward voltage drop of 0.5 V to maximize efficiency.
Mount type is surface mount providing easy integration into automated assembly processes.
Pin count of 2 simplifies circuit interfacing in power and rectification applications.

Product Description

STMicroelectronics STPS0560Z is a high efficiency Schottky Barrier Diode designed for low voltage power applications requiring high speed switching and low forward voltage drop. It features a maximum continuous forward current of 500 mA and can withstand a peak reverse repetitive voltage of 60 V. This makes it suitable for power rectification and protection roles in industrial, consumer electronics, automotive, and telecommunications sectors.

The diode is packaged in a compact 2-pin SOD-123 surface-mount package with dimensions 2.85 mm length, 1.7 mm width, and 1.35 mm height, allowing for high-density PCB layouts. It supports a peak non-repetitive forward surge current of 5.5 A, enabling it to handle transient power spikes effectively.

Operating temperature range from -65°C to 150°C ensures reliability under rigorous operating environments. With a typical forward voltage drop of 0.5 V, the STPS0560Z reduces power loss and heat dissipation, enhancing energy efficiency in power circuits.

Applications include power supplies, voltage clamping, reverse polarity protection, and general rectification tasks in electronic devices. The diode’s surface mount form factor simplifies automated pick-and-place assembly, increasing production efficiency in manufacturing processes.

Maximum continuous forward current of 500 mA ensures robust current handling. Peak reverse repetitive voltage of 60 V secures protection against voltage spikes. Compact SOD-123 package supports high density PCB design. Wide operating temperature range from -65°C to 150°C.

Low forward voltage drop of 0.5 V optimizes efficiency. Surface mount design enables automated assembly compatibility. Peak non-repetitive surge current of 5.5 A accommodates transient currents. Pin count of 2 facilitates circuit integrations.

The STMicroelectronics STPS0560Z Schottky diode is a dependable component suitable for industrial, electronic manufacturing, automotive, and consumer electronics applications requiring efficient power rectification and protection. Explore further STMicroelectronics semiconductor solutions and other diode components on EnvMart for your design and production needs.

Explore more products in our Schottky Diodes & Rectifiers category.
