Molex MicroClasp Series 8 Contact Straight Through Hole PCB Header 2 mm Pitch 1 Row Shrouded 55932-0810

Molex 55932-0810 MicroClasp Series Straight Through Hole PCB Header is engineered for robust wire-to-board connections with an 8-contact single-row design at 2 mm pitch. This connector features a shrouded housing made from high-quality polyester to provide durability and withstand operating temperatures from -40°C up to 105°C. Rated for 3 A current and 250 V voltage, it provides reliable electrical performance in demanding industrial and electronic applications.

The MicroClasp connector system includes a unique inner positive lock mechanism offering secure retention, latch protection, and an audible mating click for assembly assurance. Its low insertion and withdrawal forces reduce wear and ease maintenance. Contact and plating are made of tin to ensure excellent conductivity and corrosion resistance.

The through-hole mount type with 3.2 mm tail pin length ensures sturdy PCB attachment, while the 2 mm mating pin length aligns with standard PCB designs. This product suits various applications such as electronics manufacturing, industrial controls, power distribution boards, and instrumentation where space savings and secure connections are critical.

Users benefit from easy mating/unmating facilitated by the housing lance system and two-point contact design, maximizing signal integrity while minimizing mechanical stress. This connector is manufactured in Japan, assuring high-quality standards.

Overall, the Molex 55932-0810 MicroClasp PCB Header is ideal for compact, multi-contact electronic assembly uses in industrial, laboratory, and manufacturing sectors, providing dependable performance and ease of integration.

Features a 2.00 mm pitch for compact PCB spacing. Offers 8 male contacts in a single row for efficient signal transmission. Constructed with a polyester housing for durability and thermal stability. Supports a current rating of 3 A ensuring reliable power delivery.

Shrouded design provides secure mating with latch protection and audible click. Through-hole mount type suitable for robust PCB assembly. Rated for up to 250 V operating voltage and temperature range from -40°C to 105°C.

Contact and plating material is tin, resisting corrosion and ensuring conductivity. Includes a tail pin length of 3.2 mm and mating pin length of 2 mm for proper insertion. Ideal for electronic assemblies requiring compact, secure connectors.
