Samtec FTSH Series Vertical Surface PCB Header, 16 Contacts, 1.27 mm Pitch, 2 Row, Unshrouded FTSH-108-01-LM-DV-K-P-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Vertical |
| Current | 3.4A |
| Model | FTSH-108-01-LM-DV-K-P-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | FTSH |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- This PCB header features a high-quality phosphor bronze contact material plated with gold for superior conductivity and corrosion resistance.
- The housing is made of liquid crystal polymer, ensuring durability and thermal stability.
- It supports a current rating of 3.4 A, suitable for various electronic applications.
- This surface mount vertical header is unshrouded with a dual vertical row configuration for efficient PCB stacking.
- The operating temperature range is from -55°C to 125°C, making it suitable for industrial environments.
- Termination is by solder, offering a secure and permanent connection.
- The product is packaged on tape and reel, compatible with pick & place manufacturing processes.
Product Description
Samtec FTSH-108-01-LM-DV-K-P-TR Vertical Surface PCB Header is engineered for precision board-to-board connections with 16 male contacts arranged in two vertical rows and a 1.27 mm pitch. Designed using high-quality liquid crystal polymer housing, it withstands demanding operational conditions and offers excellent mechanical strength and thermal resistance.
The phosphor bronze contacts plated with gold provide exceptional electrical performance and corrosion resistance, ensuring long-lasting reliability. Rated for 3.4 A current, this unshrouded dual row header supports a wide range of industrial and commercial electronics, including telecommunications, computing, and instrumentation.
The product operates reliably within a temperature range from -55°C to 125°C, making it suitable for harsh environments. The surface mount design facilitates easy integration into printed circuit boards, optimized for modern assembly techniques using solder termination and pick & place automation.
Additional features include a keying shroud for correct mating and tape and reel packaging that supports automated manufacturing processes. This header is ideal for applications requiring durable, compact, and high-performance board connector solutions in industrial, laboratory, manufacturing, and electronics assembly environments.
Constructed with a liquid crystal polymer housing for durability and thermal resistance. Phosphor bronze contacts plated with gold ensure optimal conductivity and longevity. Supports a current rating of 3.4 A with solder termination for secure connections.
Unshrouded, dual vertical row configuration for efficient PCB stacking and design flexibility. Operating temperature range from -55°C to 125°C suitable for various industrial applications. Surface mount type enables seamless PCB integration with automated assembly processes.
Packaged on tape and reel compatible with pick & place manufacturing.
Choose Samtec FTSH series for a reliable and high-performance PCB header solution. Explore more PCB Headers and connectors at EnvMart to find components tailored to your industrial and electronic assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3.4 A, making it suitable for various electronic applications.
The contacts are arranged with a pitch of 1.27 mm, allowing for compact board designs.
The operating temperature range is from -55°C to 125°C, suitable for harsh industrial environments.
The housing is made of liquid crystal polymer, while the contacts are constructed from phosphor bronze and plated with gold for superior conductivity.
This model features 16 male contacts arranged in two vertical rows.
It uses solder termination, providing a secure and permanent connection to the PCB.
This PCB header is unshrouded, allowing for flexible PCB stacking configurations.
The orientation of this model is vertical, designed for efficient board-to-board connections.
It is packaged on tape and reel, making it compatible with pick & place manufacturing processes.
It supports a board-to-board connector system, ideal for various electronic applications.
The country of origin for this product is India.
The housing is made from liquid crystal polymer, ensuring durability and thermal stability.
