KEMET Film Capacitor X1, ±20 % Tolerance, 680 nF Capacitance, 440V AC Rated Voltage, Through Hole Mount PHE844
Specifications
| Country of Origin | India |
|---|---|
| Brand | KEMET |
| Height | 28mm |
| Length | 31.5mm |
| Model | PHE844 |
| Packaging | Tape & Reel |
| Width | 17.5mm |
| Mount Type | Through Hole |
| Series | PHE844 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±20 % |
| Capacitance | 680nF |
| Minimum Operating Temperature | -40°C |
| Dissipation Factor | 0.4% |
| Lead Length | 6mm |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 440V ac |
| Lead Pitch | 27.5mm |
| Lead Diameter | 0.8mm |
| Suppression Class | X1 |
Key Features
- Capacitance of 680 nF rated for 440V AC operation.
- Manufactured for through hole mounting with a lead pitch of 27.5 mm.
- Encapsulated in self-extinguishing UL94V-0 compliant material for safety.
- Suitable for operating temperatures from -40°C up to 105°C.
- Designed to meet RoHS environmental compliance standards.
- Suppression class X1 for safe use across mains supply lines.
- Lead length of 6 mm and lead diameter of 0.8 mm for easy PCB insertion.
- Typical dissipation factor of 0.4% to ensure minimal power loss.
Product Description
KEMET PHE844 Film Capacitor is a high-quality metallised polypropylene type capacitor intended for interference suppression in X1 and across line applications. This capacitor series is encapsulated with flame-retardant material compliant with UL94V-0 standards, ensuring excellent electrical safety and reliability under demanding conditions.
Featuring a capacitance of 680 nF with a tolerance of ±20 %, it is rated to handle 440 V AC voltage, making it ideal for EMI suppression in power supplies and electronic modules used in industrial and commercial equipment.
The device is designed for through hole mounting with a lead pitch of 27.5 mm, lead length of 6 mm, and a lead diameter of 0.8 mm, facilitating secure and stable circuit board assembly.
This film capacitor operates reliably within a wide temperature range from -40°C to +105°C, providing durability for varied environmental conditions often encountered in manufacturing, industrial controls, and consumer electronics.
The PHE844 series meets RoHS compliance requirements and is approved by ENEC, UL, and CSA standards, guaranteeing environmental safety and conformity to technical regulations. Capacitance of 680 nF rated for 440V AC operation.
Manufactured for through hole mounting with a lead pitch of 27.5 mm. Encapsulated in self-extinguishing UL94V-0 compliant material for safety. Suitable for operating temperatures from -40°C up to 105°C. Designed to meet RoHS environmental compliance standards.
Suppression class X1 for safe use across mains supply lines. Lead length of 6 mm and lead diameter of 0.8 mm for easy PCB insertion. Typical dissipation factor of 0.4% to ensure minimal power loss. Height 28 mm, length 31.5 mm, and width 17.5 mm dimensions for compact PCB layouts.
Ideal for use in industrial electronics, telecommunications, power supplies, and filtering applications, this capacitor ensures enhanced EMI suppression and reliable circuit protection.
Explore more Film Capacitors and electronic components on EnvMart for your engineering and design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 680 nF with a tolerance of ±20%.
It is rated for 440V AC operation, making it suitable for various applications including EMI suppression.
This unit has a height of 28 mm, a length of 31.5 mm, and a width of 17.5 mm.
It features a through hole mount with a lead pitch of 27.5 mm, a lead length of 6 mm, and a lead diameter of 0.8 mm.
The maximum operating temperature is 105°C, while the minimum operating temperature is -40°C.
This capacitor meets RoHS compliance requirements and is approved by ENEC, UL, and CSA standards.
The typical dissipation factor is 0.4%, which helps ensure minimal power loss during operation.
This capacitor is ideal for use in industrial electronics, telecommunications, power supplies, and filtering applications.
It is classified as an X1 suppression capacitor, designed for safe use across mains supply lines.
This model is packaged in Tape & Reel format, facilitating easy handling and assembly.
It is encapsulated in self-extinguishing UL94V-0 compliant material for enhanced safety.
The KEMET PHE844 has a pin count of 2, which is standard for through hole mounting.
