Infineon Type N-Channel IGBT 220 A 950 V 22-Pin EasyPACK Clamp F3L400R10W3S7FB11BPSA1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Height | 12.2mm |
| Length | 109.9mm |
| Model | F3L400R10W3S7FB11BPSA1 |
| Width | 62mm |
| Mount Type | Clamp |
| Series | F3L |
| Maximum Operating Temperature | 150°C |
| Package Type | EasyPACK |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 22 |
| Maximum Continuous Collector Current Ic | 220A |
| Maximum Collector Emitter Voltage Vceo | 950V |
| Maximum Collector Emitter Saturation Voltage VceSAT | 1.5V |
| Channel Type | Type N |
| Maximum Power Dissipation Pd | 20mW |
| Maximum Gate Emitter Voltage VGEO | 20 V |
Key Features
- Designed for high power dissipation up to 20 mW with efficient thermal management.
- Constructed with Type N channel technology ensuring fast switching and low loss.
- Operates reliably over a temperature range from -40°C to 150°C.
- Compact physical dimensions measuring 109.9 mm length, 62 mm width, and 12.2 mm height.
- Equipped with 22 pins in EasyPACK format for robust mounting via clamp method.
- Maximum gate emitter voltage of 20 V and collector-emitter saturation voltage of 1.5 V optimize electrical performance.
- Complies with RoHS environmental standards for safe and eco-friendly application.
- Suitable for industrial, power electronics, inverter, and automotive power control applications.
Product Description
Infineon F3L400R10W3S7FB11BPSA1 is a Type N-Channel Insulated Gate Bipolar Transistor (IGBT) module designed for high power electronic switching applications. It features a maximum continuous collector current of 220 A and can withstand collector-emitter voltages up to 950 V. Packaged in a 22-pin EasyPACK clamp design, the module facilitates secure installation and excellent thermal dissipation.
The device supports operation over a broad temperature range, from -40°C to 150°C, making it ideal for demanding industrial environments. Its maximum power dissipation of 20 mW ensures efficient energy management under heavy loads. With a maximum gate emitter voltage of 20 V and a collector-emitter saturation voltage of 1.5 V, this IGBT delivers fast switching and minimal conduction losses.
The EasyPACK packaging standard provides mechanical robustness and reduced design complexity for power electronics hardware. RoHS compliance guarantees adherence to environmental safety standards.
Applications include inverter systems, power supplies, motor drives, and power management in automotive and renewable energy sectors. This module's 3-level topology reduces filter size, weight, and cost, while the inclusion of 1200 V CoolSiC™ diodes lowers switching losses effectively, enhancing overall system efficiency.
High current and voltage rating suitable for industrial power electronics. Reliable operation across wide temperature range. Compact and durable EasyPACK clamp package. Low switching loss and soft turn-off behavior. Meets RoHS environmental standards.
Compatible with industrial, laboratory, HVAC, and manufacturing applications. Provides effective thermal management and secure mounting.
The Infineon F3L400R10W3S7FB11BPSA1 exemplifies a high-quality semiconductor solution tailored for robust power switching applications. Explore the broad range of high-performance IGBT Modules and power semiconductors available to optimize your industrial power control systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous collector current for this model is 220 A.
It can withstand a maximum collector-emitter voltage of 950 V.
This unit operates reliably over a temperature range from -40°C to 150°C.
The EasyPACK design features 22 pins for robust mounting.
The maximum gate emitter voltage for this model is 20 V.
The collector-emitter saturation voltage is 1.5 V.
The dimensions are 109.9 mm in length, 62 mm in width, and 12.2 mm in height.
It uses a clamp mounting type for secure installation.
The maximum power dissipation for this model is 20 mW.
It is suitable for industrial, power electronics, inverter, and automotive power control applications.
This model complies with RoHS environmental standards for safe and eco-friendly application.
The country of origin for this model is India.
