TDK 6045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 2.2 μH ±30% 7.5 A Idc VLS6045EX-2R2N-H

TDK VLS6045EX-2R2N-H is a shielded wirewound surface mount inductor with a ferrite core, designed for power circuit applications requiring high current handling capability and low electromagnetic interference.

This 6045 package inductor delivers an inductance of 2.2 μH with a tolerance of ±30%, capable of sustaining a maximum DC current of 7.5 A while maintaining a low DC resistance of 25 mΩ.

The magnetic shield construction incorporates ferrite magnetic material, offering high magnetic shielding performance and enabling compatibility with high-density mounting on printed circuit boards.

The inductor meets automotive quality and reliability standards with AEC-Q200 certification, ensuring robust performance across a wide operating temperature range from -40°C to 125°C.

Featuring surface mount termination, it supports tape and reel packaging which is compatible with automated surface mount technology (SMT) assembly processes. Ferrite core reduces magnetic losses and enhances efficiency.

Shielded design protects adjacent components from magnetic interference. Robust operating temperature range suitable for automotive and industrial use. Compact 6045 package dimensions (6mm length, 4.5mm height, 6.3mm depth) optimize board space.

Compliance with RoHS directive ensures environmental safety. AEC-Q200 certification guarantees automotive-grade reliability.

This shielded wirewound surface mount inductor is ideal for use in industrial electronics, automotive power management, telecommunications equipment, and other applications requiring efficient power filtering and noise suppression. Its high current capacity and low resistance make it well suited for high-performance power supply circuits and embedded device designs.
