TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 22 μH ±20% 2.4 A Idc VLS6045EX-220M-H
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 6mm |
| Model | VLS6045EX-220M-H |
| Depth | 6.3mm |
| Packaging | Tape & Reel |
| Series | VLS-EX-H |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | RoHS |
| Package/Case | 6045 |
| Maximum DC Current | 2.4A |
| Maximum DC Resistance | 137mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a ferrite core for enhanced magnetic shielding.
- Compact 6045 package with 6 mm length, 4.5 mm height, and 6.3 mm depth.
- Maximum DC resistance of 137 mΩ to ensure efficient performance.
- Suitable for high-density mounting with tape and reel packaging.
- Automotive grade compliant with AEC-Q200 standard for reliability.
- Operates reliably from -40°C to 125°C temperature range.
- Inductance tolerance of ±20% for precise circuit design.
- Optimized for power circuits requiring shielded wirewound inductors.
Product Description
TDK VLS6045EX-220M-H is a shielded wirewound surface mount inductor featuring a ferrite core that provides excellent magnetic shielding suited for power circuits. With an inductance of 22 μH ±20% and a maximum DC current rating of 2.4 A, this inductor offers dependable performance in demanding environments.
Housed in a compact 6045 package measuring 6 mm in length, 4.5 mm in height, and 6.3 mm in depth, it is designed for high-density mounting applications. The ferrite core construction not only achieves superior magnetic shielding but also optimizes current capacity and minimizes resistance, offering a maximum DC resistance of just 137 mΩ.
This product complies with the automotive industry standard AEC-Q200, ensuring robustness and reliability for automotive electronic applications. The inductor functions effectively within a wide temperature range of -40°C to 125°C, making it suitable for harsh environmental conditions.
The inductance tolerance of ±20% supports precise tuning and reliable circuit operation. Packaging is delivered on tape and reel, suitable for automated PCB assembly processes.
This shielded inductor series from TDK is ideal for various industries, including industrial electronics, automotive power electronics, telecommunications, and consumer electronics where robust inductors with low EMI are required.
Constructed with a ferrite core for enhanced magnetic shielding. Compact 6045 package with 6 mm length, 4.5 mm height, and 6.3 mm depth. Maximum DC resistance of 137 mΩ to ensure efficient performance. Suitable for high-density mounting with tape and reel packaging.
Automotive grade compliant with AEC-Q200 standard for reliability. Operates reliably from -40°C to 125°C temperature range. Inductance tolerance of ±20% for precise circuit design. Optimized for power circuits requiring shielded wirewound inductors.
Explore the TDK Surface Mount Inductors category on EnvMart for more premium passive components designed to meet industrial and automotive standards.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 22 μH with an inductance tolerance of ±20%.
This inductor has a maximum DC current rating of 2.4 A.
The dimensions of the 6045 package are 6 mm in length, 4.5 mm in height, and 6.3 mm in depth.
The maximum DC resistance is 137 mΩ, which helps ensure efficient performance.
It operates reliably within a temperature range of -40°C to 125°C.
The core material of this inductor is ferrite, which enhances magnetic shielding.
Yes, it complies with the AEC-Q200 automotive standard, ensuring reliability for automotive applications.
It is packaged on tape and reel, making it suitable for automated PCB assembly processes.
The termination style of this model is surface mount.
This inductor complies with RoHS standards.
It is optimized for power circuits requiring shielded wirewound inductors, suitable for various industries including automotive and telecommunications.
This inductor belongs to the VLS-EX-H series.
