STMicroelectronics 100 V 40 A Schottky Diode Surface Mount TO-263 3-Pin STPS41H100CG-TR
Specifications
| Country of Origin | China |
|---|---|
| Brand | STMicroelectronics |
| Height | 9.35mm |
| Length | 10.4mm |
| Model | STPS41H100CG-TR |
| Width | 4.6mm |
| Mount Type | Surface |
| Series | STPS41H100C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 40A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 220A |
| Maximum Forward Voltage Vf | 900mV |
| - Capacitance | 45 pF |
Key Features
- High continuous forward current capacity of 40 amperes.
- Peak reverse repetitive voltage rating of 100 volts.
- Low forward voltage drop of 900 millivolts ensures efficient conduction.
- Handles peak non-repetitive forward surge current up to 220 amperes.
- Operates within a temperature range from -65°C to 175°C.
- Features a common cathode diode configuration ideal for secondary rectification.
- Low peak reverse current of 10 milliamperes reduces leakage losses.
- Surface mount TO-263 (D2PAK) package with insulated ISOTOP housing offers 2500 VRMS isolation.
Product Description
STMicroelectronics STPS41H100CG-TR is a high-performance Schottky diode designed specifically for high frequency switch mode power supplies. It supports a maximum continuous forward current of 40A and a peak reverse repetitive voltage of 100V, making it suitable for robust power rectification tasks in industrial and commercial electronics.
This diode features a low forward voltage drop of 900mV that improves efficiency by reducing power losses during conduction. It has an excellent surge current capability of 220A to handle transient overloads safely.
Its common cathode configuration and 3-pin TO-263 surface mount insulated ISOTOP package offer convenient mounting options and electrical insulation, rated for 2500 VRMS isolation. The device operates reliably over a wide temperature range from -65°C to 175°C.
With a capacitance of 45 pF, it provides excellent performance in high frequency circuits. The STPS41H100CG-TR diode exhibits low leakage current with a peak reverse current of only 10mA, making it ideal for power conversion, industrial automation, and renewable energy applications.
High continuous forward current capacity of 40 amperes. Peak reverse repetitive voltage of 100 volts for reliable blocking. Low forward voltage drop of 900 millivolts enhances power efficiency. Surge current rating of 220 amperes supports transient overloads.
Wide operating temperature range from -65°C to 175°C ensures durability. Common cathode configuration suited for secondary rectification. Surface mount TO-263 insulated ISOTOP package with 2500 VRMS isolation. Capacitance of 45 pF for high frequency circuit compatibility.
Manufactured in China following industry standards.
This diode is widely used in industrial power supplies, switch mode power converters, telecommunications, automotive power circuits, and renewable energy systems requiring efficient rectification and fast recovery characteristics.
Explore more Schottky Diodes & Rectifiers at EnvMart to suit your power electronics applications with high reliability and performance.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 40A.
It has a peak reverse repetitive voltage rating of 100V.
The forward voltage drop is 900mV, which enhances power efficiency during conduction.
This diode can handle a peak non-repetitive forward surge current of up to 220A.
It operates reliably over a temperature range from -65°C to 175°C.
It features a common cathode diode configuration, which is ideal for secondary rectification.
The dimensions of the TO-263 package are 10.4mm in length, 4.6mm in width, and 9.35mm in height.
The peak reverse current is 10mA, which helps reduce leakage losses.
The capacitance is 45 pF, making it suitable for high frequency circuits.
This model supports surface mounting, specifically in a TO-263 package.
It is manufactured in China following industry standards.
It is suitable for use in industrial power supplies, switch mode power converters, telecommunications, automotive power circuits, and renewable energy systems.
