onsemi 16 V General Purpose Zener Diode, Through Hole 2-Pin SOD-27, 500 mW Power Dissipation, 5% Tolerance 1N5246BTR

onsemi 1N5246BTR is a general purpose Zener diode designed for precise voltage regulation in electronic circuits. With a nominal Zener voltage of 16 V and a maximum power dissipation of 500 mW, this diode provides reliable operation in a Through Hole SOD-27 package.

The diode configuration is single element with a pin count of two, suitable for Through Hole mounting on printed circuit boards (PCB). It is designed to operate across a temperature range from -65°C to 200°C, supporting demanding industrial and electronic applications.

This Zener diode exhibits low maximum reverse leakage current of 100 nA, contributing to energy efficiency in sensitive circuits. Its maximum Zener impedance is rated at 17 ohms, ensuring stable voltage regulation during test currents of 7.8 mA.

The compact SOD-27 package measures 4.56 mm in length and 1.91 mm in height, making it ideal for installations with space constraints. Nominal Zener Voltage: 16 V. Maximum Power Dissipation: 500 mW. Pin Count: 2. Operating Temperature: -65°C to 200°C.

Package Type: Through Hole SOD-27. Maximum Reverse Leakage Current: 100 nA. Maximum Zener Impedance: 17 Ω. This diode is commonly used in industrial, laboratory, manufacturing, and electronic design applications requiring stable voltage references or protection circuits.
