onsemi 1.3 V 500 mW 5% Voltage Regulator Zener Diode Single Surface Mount 2-Pin SOD-523 MM5Z3V0T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi 1.3 V 500 mW 5% Voltage Regulator Zener Diode Single Surface Mount 2-Pin SOD-523 MM5Z3V0T1G

Name: onsemi 1.3 V 500 mW 5% Voltage Regulator Zener Diode Single Surface Mount 2-Pin SOD-523 MM5Z3V0T1G
Brand: onsemi
SKU: 106730
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	0.7mm
Length	1.7mm
Model	MM5Z3V0T1G
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOD-523
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	10μA
Nominal Zener Voltage Vz	3V
Zener Type	Voltage Regulator
Maximum Zener Impedance	100Ω
Typical Voltage Temperature Coefficient	0mV/K
Surface Mount case	SOD-523

Key Features

This diode has a nominal Zener voltage of 3 V with ±5% tolerance.
It supports a maximum power dissipation of 500 mW suitable for low-power voltage regulation.
The package type is SOD-523, ideal for surface mount applications requiring compact size.
The diode features a maximum reverse leakage current of 10 μA and maximum Zener impedance of 100 Ω.
It operates reliably within a temperature range of -65°C to 150°C for industrial and commercial use.
The device is RoHS compliant, ensuring environmental safety.
Its height and length dimensions are 0.7 mm and 1.7 mm respectively, supporting PCB space-constrained designs.
The test current for this diode is 5 mA, ensuring stable voltage regulation at this current level.

Product Description

onsemi MM5Z3V0T1G is a single element Zener Diode designed as a voltage regulator with a nominal Zener voltage of 3 V and a tolerance of ±5%. It supports a maximum power dissipation of 500 mW and comes in a SOD-523 surface mount package with 2 pins, making it optimal for modern compact electronic devices.

The diode operates within a wide temperature range from -65°C to 150°C, ensuring reliable performance in industrial, commercial, and electronic component manufacturing sectors. Its low reverse leakage current of 10 µA and Zener impedance of 100 Ω contribute to precise and stable voltage regulation under specified test current conditions of 5 mA.

Featuring a compact height of 0.7 mm and length of 1.7 mm, this surface mount diode is suitable for applications where PCB real estate is limited. It is RoHS compliant, aligning with industry environmental standards and making it suitable for environmentally conscious designs.

This product is ideal for use in power & connectors assemblies, semiconductor devices, and discrete semiconductor components in a variety of electronics including consumer electronics, embedded systems, and industrial controllers.

This diode has a nominal Zener voltage of 3 V with ±5% tolerance. It supports a maximum power dissipation of 500 mW suitable for low-power voltage regulation. The package type is SOD-523, ideal for surface mount applications requiring compact size.

The diode features a maximum reverse leakage current of 10 μA and maximum Zener impedance of 100 Ω. It operates reliably within a temperature range of -65°C to 150°C for industrial and commercial use. The device is RoHS compliant, ensuring environmental safety.

Its height and length dimensions are 0.7 mm and 1.7 mm respectively, supporting PCB space-constrained designs. The test current for this diode is 5 mA, ensuring stable voltage regulation at this current level. This product is rated as new and suitable for a wide range of electronic assemblies and repair tasks.
