onsemi Logic Level Translator Uni-Directional ECL to LVTTL 3V to 3.6V 8-Pin SOIC MC100EPT25DG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 5mm |
| Model | MC100EPT25DG |
| Mount Type | Surface |
| Output type | LVTTL |
| Series | MC100EPT2 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Number of Elements per Chip | 2 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | ECL |
| Logic Function | Translator |
| Minimum Supply Voltage | 3V |
| Maximum High Level Output Current | -3mA |
| Maximum Propagation Delay Time @ CL | 2ns |
| Direction Type | Uni-Directional |
| Maximum Low Level Output Current | 24mA |
| Translation | ECL to LVTTL |
Key Features
- Operates at a supply voltage range of 3V to 3.6V.
- Maximum propagation delay time of 2 nanoseconds ensures fast signal translation.
- Supports up to 24mA low level output current and -3mA high level output current.
- Operating temperature range from -40°C to 85°C for robust performance.
- Small outline 8-lead SOIC package ideal for surface mounting on PCBs.
- Uni-directional translation with 2 elements per chip.
- Typical propagation delay of 1.1 nanoseconds and maximum frequency over 275 MHz.
- VBB output supports single-ended input mode with bypass capacitor for stability.
Product Description
onsemi MC100EPT25DG is a high-performance logic level translator designed for uni-directional translation from Differential LVECL/ECL to LVTTL logic levels. Packaged in a compact 8-pin SOIC format, this device requires a supply voltage range from 3.0V to 3.6V and operates reliably within a temperature range of -40°C to 85°C.
The device features a maximum propagation delay time of 2 nanoseconds at typical load capacitance conditions, enabling high-speed data or clock signal translation with typical delay as low as 1.1 nanoseconds. With a maximum operating frequency exceeding 275 MHz, it suits industrial and electronic applications requiring fast switching.
The MC100EPT25DG supports a maximum low-level output current of 24mA and a high-level output current of -3mA. Its unique VBB output pin enables operation in single-ended input mode, facilitating both inverting and non-inverting buffer configurations by tying the VBB output to the data input with proper bypassing.
This device is well suited for circuit designs requiring reliable logic translation under demanding conditions, including industrial controls, telecommunications, and instrumentation systems. Its surface mount 8-lead SOIC package allows space-efficient PCB layout while ensuring electrical performance.
Operates at 3V to 3.6V supply voltage with ECL to LVTTL translation. Surface mount 8-pin SOIC package for easy integration. Low propagation delay time and high-frequency operation. Wide operating temperature range from -40°C to 85°C.
Pb-free package compliant with environmental safety standards. Supports single-ended input mode operation via VBB pin. Ideal for industrial, laboratory, and communication system applications. Explore more Logic ICs and translators at EnvMart for industrial and electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates at a supply voltage range of 3.0V to 3.6V.
The maximum propagation delay time is 2 nanoseconds under typical load capacitance conditions.
It supports a maximum operating frequency exceeding 275 MHz.
The output type is LVTTL, which is suitable for low-voltage TTL applications.
It operates reliably within a temperature range of -40°C to 85°C.
This device contains 2 elements per chip, allowing for efficient logic translation.
The dimensions are 5mm in length and 1.5mm in height, packaged in an 8-pin SOIC format.
It supports a maximum low-level output current of 24mA.
The VBB output pin supports single-ended input mode operation and can be used for both inverting and non-inverting buffer configurations.
The maximum high-level output current is -3mA.
It is designed for surface mounting, making it suitable for compact PCB layouts.
This model is well-suited for industrial controls, telecommunications, and instrumentation systems requiring reliable logic translation.
