onsemi Transistor 800 mA NPN 40 V 3-Pin SOT-23 BSR14

onsemi BSR14 Transistor is a reliable small signal NPN bipolar junction transistor designed for efficient switching and amplification in electronic circuits. It is packaged in a 3-pin SOT-23 surface mount configuration, making it suitable for compact PCB layouts in industrial, consumer electronics, and telecommunications applications.

This transistor supports a maximum DC collector current of 800 mA and can withstand collector-emitter voltages up to 40 V, providing robust performance under moderate power conditions. Its minimum DC current gain (hFE) of 50 and maximum transition frequency of 300 MHz enable effective signal amplification and switching at high frequencies.

The device operates reliably across a wide temperature range from -55°C to 150°C, making it suitable for demanding environments such as industrial automation and telecommunications equipment.

With a power dissipation rating of 350 mW, the BSR14 transistor fits well in compact designs without excessive heat generation. Its RoHS compliance ensures environmental safety by restricting hazardous substances.

Physical dimensions of 2.92 mm in length, 1.3 mm in width, and 1.2 mm in height, combined with the surface mount SOT-23 package type, allow easy integration into automated assembly lines and high-density circuit boards.

The transistor has a maximum DC collector current of 800 mA. It supports a maximum collector-emitter voltage of 40 volts. Housed in a compact 3-pin SOT-23 surface mount package. Features a minimum DC current gain (hFE) value of 50.

It operates within a temperature range of -55°C to 150°C for reliable performance. The maximum power dissipation is rated at 350 milliwatts. Designed with NPN transistor polarity and single transistor configuration. Maximum transition frequency (ft) is specified at 300 MHz.

Complies with RoHS standards for environmental safety. Measures approximately 2.92 mm length, 1.3 mm width, and 1.2 mm height.

This component is ideal for use in electronic designs requiring efficient switching and amplification, including industrial controls, consumer electronics, and telecommunications devices.
