Molex C-Grid III Series Straight Through Hole PCB Header, 12 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 90130-1112
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
Key Features
- Features a shrouded straight locking header for secure locking housing compatibility.
- Constructed with brass contacts plated with tin for durability and efficient conductivity.
- Supports a maximum operating temperature of 125°C and minimum of -55°C for versatile thermal performance.
- Operates at a voltage rating of 350V and a current rating of 3A suitable for various electronic applications.
- The tail pin length is 2.9 mm, designed for solder termination on printed circuit boards.
- Complies with Molex C-Grid III series standards ensuring industry compatibility and reliability.
- Ideal for electronic, electrical, and industrial equipment requiring robust PCB connections.
Product Description
The Molex 90130-1112 model is a C-Grid III Series PCB Header designed for through hole mounting on printed circuit boards, featuring 12 male contacts arranged in 2 rows with a 2.54 mm pitch. This shrouded straight locking header is suited for wire-to-board connector systems, providing secure and reliable connections in demanding electronic assemblies.
Manufactured with brass contact material and tin plating, this header provides excellent electrical conductivity and corrosion resistance. It supports a current of 3 amperes and a voltage of up to 350 volts, making it ideal for a wide range of industrial, electronic, and electrical applications including instrumentation, communication equipment, and control systems.
The operating temperature range extends from -55°C up to 125°C, accommodating harsh thermal environments. The tail pin length of 2.9 mm is optimized for effective solder termination ensuring strong mechanical and electrical joints on PCBs.
Designed within the Molex C-Grid III series, this product emphasizes compatibility with locking housings for streamlined assembly processes and enhanced connector security. The shrouded design adds an additional layer of protection to the contacts against damage and ensures correct mating.
Ideal uses include industrial electronics, telecommunications hardware, laboratory instrumentation, automation equipment, and other applications requiring durable and precise PCB connector solutions.
Shrouded straight locking header with 12 brass contacts plated with tin. 2 rows with 2.54 mm pitch for standard PCB layouts. Wire-to-board connector system with through hole mount type. Rated for 3A current and 350V voltage for reliable operation.
Operates in wide temperature range from -55°C to 125°C. Tail pin length of 2.9 mm for solder termination ensuring strong connections. Suitable for electronic, industrial, and electrical applications requiring PCB headers.
Explore Molex PCB Headers and other connector solutions in the Electronics Components category at EnvMart to enhance your circuit board assembly and connectivity projects.
