Molex C-Grid Series Vertical Through Hole PCB Header 14 Contact 2.54 mm Pitch 2 Row Shrouded 70246-1404

Molex 70246-1404 C-Grid Series Vertical Through Hole PCB Header is a high-quality wire-to-board connector equipped with 14 male contacts arranged in 2 rows with a 2.54 mm pitch. This shrouded PCB header is designed to offer dependable electrical connections, suitable for industrial, automation, and consumer electronics applications requiring reliable signal and power distribution.

The header features phosphor bronze contacts plated with gold to ensure excellent conductivity and resistance against corrosion. Its through hole mount type and solder tail pin length of 3.43 mm facilitate secure and stable soldering onto the PCB, supporting effective mechanical and electrical integrity.

With a voltage rating of 250 V DC and a nominal current rating of 2.5 A per contact, this component meets demanding power distribution requirements without overheating. Operating over an extended temperature range of -40°C to 120°C, it is fit for use in various environmental conditions. The shrouded design helps prevent accidental disconnections and misalignments, increasing connector reliability in high-density PCB assemblies.

Applications include automation control systems, industrial equipment wiring configurations, and compact consumer electronic devices, where space efficiency and connection security are paramount. It is recommended for use with PCBs of 1.60 mm thickness to ensure correct fit and electrical performance.

Supports a maximum current rating of 2.5A per contact. Phosphor bronze contacts with gold plating provide dependable conductivity and corrosion resistance. Through hole mounting method ensures secure PCB attachment. Rated for safe operation up to 250 V DC voltage.

Shrouded housing prevents accidental disconnections and misalignment. Extended operating temperature range from -40°C to 120°C. Male contact gender with solder tail pin termination. 2-row vertical orientation optimizes PCB space usage.

Designed for signal transmission and power distribution in industrial and consumer electronics. Ideal for automation control wiring and industrial equipment connections.

Choose Molex C-Grid Series PCB Header 70246-1404 for efficient, robust, and secure PCB connectivity solutions. Browse our Electronics Components and PCB Headers selections at EnvMart for more industrial-grade connector options.
