TDK HighE Varistor 2.2nF 200A Clamping 650V Diameter 32mm Length 60mm Thickness 14mm Model B72232B0251K001

Free Delivery in India | Lowest Global Shipping Charges

TDK HighE Varistor 2.2nF 200A Clamping 650V Diameter 32mm Length 60mm Thickness 14mm Model B72232B0251K001



Category Varistor Brand TDK Condition New

Specifications

Country of Origin	China
Diameter	32mm
Brand	TDK
THICKNESS	14mm
Length	60mm
Model	B72232B0251K001
Depth	55mm
Packaging	Bulk
Series	HighE
Energy Rating	330J
Maximum Operating Temperature	85°C
Capacitance	2.2nF
Minimum Operating Temperature	-40°C
Maximum dc Voltage	250V dc
Standards/Approvals	RoHS
Lead Pitch	24mm
Maximum AC Voltage	250V ac
Clamping Voltage VC	650V
Clamping Current	200A
Maximum Surge Current	25kA
Varistor Voltage	390 V

Key Features

Disk shaped block varistor element inside a flame-retardant plastic housing and sealed with potting.
Provides bidirectional ESD protection complying with IEC 61000-4-2 level 4 standards.
Maintains stable ESD protection performance up to 85°C temperature rating.
Low parasitic inductance and leakage current enable fast response time for surge suppression.
Incorporates parasitic capacitance for EMI noise suppression and high-frequency filtering.
Capable of handling maximum surge currents up to 25 kA for robust protection.
Lead pitch spacing of 24 mm for easy screw fixing and mounting.
Energy rating of 330 J suitable for industrial and electronic surge protection.

Product Description

TDK B72232B0251K001 is a HighE series block varistor designed for electronic surge protection. This varistor utilizes a disk-shaped element potted within a flame-retardant plastic housing with screw terminals. It features a capacitance of 2.2 nF and has a clamping current rating of 200 A and clamping voltage of 650 V, providing reliable defense against electrical surges and transient voltage spikes.

The varistor offers bidirectional electrostatic discharge (ESD) protection rated to IEC 61000-4-2, level 4, maintaining its performance consistently up to 85°C. Its low parasitic inductance and leakage current facilitate fast response times ideal for suppressing transient surges in industrial, commercial, and electronic applications.

Additionally, the component uses parasitic capacitance for effective electromagnetic interference (EMI) suppression and high-frequency filtering, which can replace the need for additional multilayer ceramic capacitors in some circuits. It can withstand maximum surge currents of up to 25 kA and has an energy rating of 330 J, making it suitable for robust power and signal line protection.

The physical dimensions include a diameter of 32 mm, length of 60 mm, thickness of 14 mm, depth of 55 mm, and a lead pitch of 24 mm that supports screw mounting. The varistor is packed in bulk and manufactured to RoHS standards in China.

This TDK varistor is well-suited for industrial electronics, power supply circuits, telecommunications equipment, and general surge protection use cases. It meets stringent quality and safety standards while delivering high durability and performance reliability.

Disk shaped block varistor with flame-retardant housing and potting. Bidirectional ESD protection meeting IEC 61000-4-2 level 4. Stable ESD response up to 85°C operating temperature. Low parasitic inductance supports fast surge response.

Parasitic capacitance for EMI suppression and filtering. High surge current handling capacity of 25 kA. Dimensions: diameter 32 mm, length 60 mm, thickness 14 mm, depth 55 mm. Lead pitch 24 mm for easy mounting. Energy rating 330 J for industrial applications.

RoHS compliant, manufactured in China. Explore more in our Electronics Components section for quality surge protection and Varistor devices by TDK and other leading manufacturers at EnvMart.
