TDK VLS5045EX-330M Wirewound Surface Mount Inductor 33μH ±20%, 1.3A, 5045, Shielded, Ferrite Core
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-330M |
| Depth | 5mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 33μH |
| Standards/Approvals | RoHS |
| Package/Case | 5045 |
| Maximum DC Current | 1.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 240mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Shielded ferrite core construction for minimal electromagnetic interference.
- Surface mount 5045 package allows high-density PCB placement.
- Delivers 33μH inductance with ±20% tolerance for precision filtering.
- Supports up to 1.3A DC current handling for robust circuit design.
- Low DC resistance of 240mΩ ensures high efficiency.
- Operates reliably from -40°C to 105°C for diverse environments.
Product Description
The TDK VLS5045EX-330M is a high-performance wirewound surface mount inductor engineered for power circuit applications in modern electronic devices. With a rated inductance of 33μH and a ±20% tolerance, this inductor is suitable for precise filtering and energy storage in diverse circuits demanding stable operation and efficiency.
Featuring a magnetically shielded design with a ferrite core, the VLS5045EX-330M reduces electromagnetic interference while allowing currents up to 1.3A. Its compact 5045 form factor (5mm x 5mm x 4.5mm) and surface mount termination facilitate efficient board space utilization, making it ideal for high-density assemblies in consumer and industrial electronics.
The device presents a maximum DC resistance of 240mΩ and is constructed using robust moulded techniques, ensuring both low Rdc and reliable thermal performance over a wide temperature span (-40°C to 105°C).
Compliant with RoHS standards and tested for durability, it is an excellent choice for demanding power supply and filter applications in TVs, game systems, set-top boxes, and audiovisual equipment.
Each unit is RoHS certified, assuring safe use in modern manufacturing environments. Common industrial applications include power supply regulation, EMI suppression, and energy storage in high-reliability circuit designs.
Choose TDK's trusted VLS5045EX-330M Surface Mount Inductor for precise, energy-efficient performance in next-generation electronic systems. For more innovative passive components, browse EnvMart’s extensive range of TDK inductors and electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 33μH with a tolerance of ±20%.
It supports a maximum DC current of 1.3A, making it suitable for various power circuit applications.
The dimensions of this unit are 5mm in length, 5mm in depth, and 4.5mm in height.
The maximum DC resistance is 240mΩ, which contributes to its efficiency in circuit designs.
It operates reliably within a temperature range of -40°C to 105°C.
The core material is ferrite, which helps in reducing electromagnetic interference.
Yes, it is RoHS compliant, ensuring safe use in modern manufacturing environments.
The termination style is surface mount, facilitating efficient PCB placement.
It is suitable for power supply regulation, EMI suppression, and energy storage in high-reliability circuit designs.
The magnetically shielded design reduces electromagnetic interference, enhancing its performance in sensitive applications.
This inductor belongs to the VLS-EX series, which is designed for high-performance applications.
The pin count for the TDK VLS5045EX-330M is 2, which is standard for surface mount inductors.
