Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 18 Contacts, Dual Row, 2.54mm Pitch, Gold Plated 61301821821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | PCB Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 18 |
| Connector System | Board-to-Board |
Key Features
- Features 18 contacts in a dual row configuration.
- 2.54 mm pitch for standard PCB designs.
- Copper alloy contacts with gold plating ensure high conductivity and longevity.
- Through-hole mounting for secure and robust installation.
- Solder termination ensures reliable connections and ease of assembly.
- Rated current up to 3A and voltage up to 500V for various electronic circuits.
- Operating temperature range from -40°C to 105°C for wide application suitability.
- RoHS compliant for environmentally friendly manufacturing and use.
Product Description
Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, model 61301821821, is designed for demanding board-to-board connection requirements in precise electronic assembly operations. Featuring 18 contacts arranged in two rows with a pitch standard of 2.54 mm, this socket enables robust, repeatable connections and is widely compatible with industry-standard PCBs.
Features 18 contacts in a dual row 2.54 mm pitch configuration for optimized circuit density. Copper alloy contact material with gold plating offers improved conductivity and reliable performance even under frequent mating cycles.
Straight through-hole orientation and solder termination greatly facilitates secure installation and maintenance. Rated for 3A and 500V, capable of handling a broad range of signal and power applications in electronics. Operating temperature ranges from -40°C to 105°C, ensuring suitability for various industrial and laboratory environments.
This PCB socket is part of the WR-PHD Series and is RoHS compliant, supporting environmentally responsible manufacturing practices. The connector system is board-to-board, making it ideal for multi-PCB designs and modular electronic assemblies.
Applications include use in industrial automation equipment, laboratory instrumentation, power distribution boards, sensor arrays, and commercial electronic devices demanding repeated mating cycles and high reliability.
With its gold-plated contacts and durable copper alloy construction, this PCB Socket guarantees long-term performance and resistance to corrosion. For browsing more PCB connectors and sockets from Wurth Elektronik, explore the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3A and a voltage of 500V, making it suitable for various electronic circuits.
It features an 18-contact configuration arranged in a dual row with a pitch of 2.54 mm, optimizing circuit density.
The socket uses solder termination, which ensures reliable connections and facilitates ease of assembly.
This PCB socket operates within a temperature range of -40°C to 105°C, suitable for various industrial and laboratory environments.
The contacts are made of copper alloy and feature gold plating, which enhances conductivity and resistance to corrosion.
Yes, this model is RoHS compliant, supporting environmentally friendly manufacturing practices.
It is designed for through-hole mounting, providing secure and robust installation on PCBs.
This model is suitable for applications in industrial automation equipment, laboratory instrumentation, power distribution boards, and sensor arrays.
It has 2 rows and a total of 18 contacts, allowing for efficient board-to-board connections.
The socket has a straight orientation, which facilitates easy installation and maintenance.
This model is part of the WR-PHD Series, designed for demanding board-to-board connection requirements.
The country of origin for this model is Taiwan.
