KEMET Polypropylene Capacitor 470 nF 1.6 kV dc 650V ac Radial Terminal ±5 % Tolerance R76TR34704030J
Specifications
| Country of Origin | India |
|---|---|
| Capacitance Range | 100 pF - 15 μF |
| Voltage Range | 250 - 2000 V dc |
| Brand | KEMET |
| Height | 37mm |
| Length | 32mm |
| Model | R76TR34704030J |
| Packaging | Tray |
| Width | 22mm |
| Series | R76 |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±5 % |
| Capacitance | 470nF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Radial |
| Dissipation Factor | 0.0003% |
| Lead Length | 30mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Pin Count | 2 |
| Rated AC Voltage | 650V ac |
| Rated DC Voltage | 1.6kV dc |
| Lead Pitch | 27.5mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±5%, ±10%, ±20% |
| Lead Spacing | 7.5 mm - 37.5 mm |
| Equivalent Series Resistance ESR | 7mΩ |
Key Features
- Rated DC voltage of 1.6 kV and AC voltage of 650V for robust performance.
- Radial terminal type with a lead pitch of 27.5 mm and lead length of 30 mm.
- Operates effectively in temperatures ranging from -55°C to 105°C.
- Constructed with double metallized polypropylene film for enhanced durability.
- Compliant with automotive standard AEC-Q200 for high reliability in electrical components.
- Encapsulated in a self-extinguishing plastic case meeting UL 94V-0 requirements.
- Suitable for suppression in switched mode power supplies and high voltage, high current circuits.
- Low equivalent series resistance (ESR) of 7 mΩ and minimal dissipation factor of 0.0003%.
Product Description
KEMET R76TR34704030J Polypropylene Capacitor is engineered for demanding industrial and electronic applications requiring high voltage and precision capacitance. This capacitor features a 470 nF capacitance with a ±5 % tolerance, ensuring stable performance in critical circuit designs.
It is rated for a maximum DC voltage of 1.6 kV and an AC voltage of 650V, making it suitable for harsh environments and high voltage switching circuits. The radial terminal type provides ease of installation with a 27.5 mm lead pitch and 30 mm lead length, facilitating compatibility with various PCB layouts.
The capacitor is built using double metallized polypropylene film technology, providing self-healing properties and long service life. It is encapsulated in a self-extinguishing solvent-resistant plastic case that complies with UL 94V-0 standards for safety.
Key features include an equivalent series resistance (ESR) of 7 mΩ and an extremely low dissipation factor of 0.0003%, which contribute to efficient energy handling and minimal heat generation. It meets automotive quality standard AEC-Q200, ensuring reliability and robustness in automotive and industrial environments.
Its operating temperature range spans from -55°C to +105°C, supporting applications in broad temperature conditions. Typical applications include switched mode power supplies (SMPS), deflection circuits in televisions, snubber circuits, and silicon-controlled rectifier (SCR) commutation circuits requiring high voltage and current handling capability.
Package type is tray supplied with 2-pin radial terminals, suitable for automated assembly lines. Dimensions are 37 mm height, 32 mm length, and 22 mm width, with a lead diameter of 0.8 mm.
Rated voltage and capacitance range ensures flexibility in design. Self-extinguishing encapsulation enhances safety. Meets RoHS and IEC 60286-2 standards. Ideal for industrial, automotive, and power electronics sectors. Explore our wide selection of Film Capacitors for reliable and efficient electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 470 nF with a tolerance of ±5%.
It is rated for a maximum DC voltage of 1.6 kV and an AC voltage of 650V.
The equivalent series resistance (ESR) of this unit is 7 mΩ.
This capacitor operates effectively within a temperature range of -55°C to 105°C.
The dimensions are 37 mm in height, 32 mm in length, and 22 mm in width, with a lead diameter of 0.8 mm.
It features radial terminals with a lead pitch of 27.5 mm and a lead length of 30 mm.
It complies with RoHS and IEC 60286-2 standards, and meets the automotive standard AEC-Q200 for reliability.
The dissipation factor is 0.0003%, contributing to efficient energy handling.
This capacitor is packaged in a tray, suitable for automated assembly lines.
It is suitable for applications such as switched mode power supplies, deflection circuits, and snubber circuits.
It is constructed with double metallized polypropylene film, providing self-healing properties.
The lead spacing for this model ranges from 7.5 mm to 37.5 mm.
